Aluminum Window Making Machinery Aluminium Profile Cutting Mullion Auto End Milling Machine

US$2,500.00 1 Piece (MOQ)

Basic Info.

Model NO.
WME-300
Condition
New
Certification
ISO, CE
Automatic Grade
Automatic
CNC or Not
not CNC
Voltage
380V
Name
Mullion Auto End Milling Machine
Model
Wme-300
Function
Aluminum Mullion Milling
Power
2.2kw
Rotary Speed
2800r/Min
Operation Air Pressure
0.6~0.8MPa
Transport Package
Wood Package
Specification
1600x860x1400 mm
Trademark
windoormaker
Origin
China
HS Code
847780000

Product Description



Product Description
Specification:
Used for aluminum mullion/transom end-milling for fitting different frame. Milling the notch and step face of mullion/transom profile. It can milling many pieces at same time. Feeding system with linear bearing, ensure the accurate and stable working. Large tools with high and stable milling speed for guarantee the working quality. Feeding system controlled by air-oil way to keep running smooth. With Siemens motor Technical Parameter:
Power supply Made to order
Operation air pressure 0.5~0.8Mpa
Motor power 2.2KW
Air consumption 80L/min
Motor rotary speed 2840r/min
Milling cutter specification φ32mmxΦ300mm
Milling deepness Max.40mm
Milling height Max. 90mm
Cutting surface roughness Ra12.5µm
Dimension 1600×860×1400 mm
Weight 250kg



Certifications

Company Profile

Jinan Windoormaker Machine CO., Ltd. Is an engineering company that has been in business for over 10 years which specialized in the manufacture and supply the UPVC & aluminum window and door machines.
Windoormaker is a factory with cover area of 15000 m² . During the years developing, has made many devotes of machine improving, introducing new equipment and technology innovation for the production.


Machine at old customer
