| Product name | CR 5-36 A-FGJ-A-E-HQQE |
| Product No | 96513394 |
| EAN number | 5700396639581 |
| Pump speed on which pump data are based | 2919 rpm |
| Rated flow | 5.8 m³/h |
| Rated head | 189.2 m |
| Maximum head | 248.4 m |
| Stages | 36 |
| Impellers | 36 |
| Number of reduced-diameter impellers | 0 |
| Low NPSH | N |
| Pump orientation | Vertical |
| Shaft seal arrangement | Single |
| Code for shaft seal | HQQE |
| Approvals | CE,EAC,UKCA,SEPRO |
| Approvals for drinking water | WRAS,ACS |
| Curve tolerance | ISO9906:2012 3B |
| Pump version | A |
| Model | A |
| Base | Cast iron |
| EN 1561 EN-GJL-200 | |
| ASTM A48-25B | |
| Impeller | Stainless steel |
| EN 1.4301 | |
| AISI 304 | |
| Material code | A |
| Code for rubber | E |
| Bearing | SIC |
| t max amb | 60 °C |
| Maximum operating pressure | 25 bar |
| Max pressure at stated temp | 25 bar / 120 °C |
| 25 bar / -20 °C | |
| Type of connection | DIN / ANSI / JIS |
| Size of inlet connection | DN 25/32 |
| Size of outlet connection | DN 25/32 |
| Pressure rating for connection | PN 25 |
| Flange rating inlet | 250 lb |
| Flange size for motor | FF265 |
| Connect code | FGJ |
