High Efficiency Plastic Crate Bucket Molding Equipment up-750t

Product Description

China Servo Injection Molding Machine
Ningbo Union Power Machinery Co., Ltd.
Modulus of Capacitance: Includes position, size, and maximum allowable modulus of capacitance and minimum closure thickness of the injection molding machine guide pillar (Green column).
Nozzle Parameters: Specifies spherical diameter, aperture, outer diameter, maximum extension length, and positioning aperture of the nozzle.
Code Mold Parameters: Covers mold hole and slot size for efficient operation.
Ejection Mechanism: Details ejection point position, ejector rod diameter, and optional ejection force and stroke.
Mold Opening Stroke: Indicates mold opening stroke and maximum opening distance for precise molding.

	Model UP-750T
Injection Unit	A	B	C
Screw diameter (mm)	100	110	120
Shot Volume (cm3)	3636	4400	5236
Injection weight (g)	3306	4003	4765
injection pressure (Mpa)	184	152	128
Screw speed (rmp)	110
Clamping Unit
Clamping force (KN)	7500
Open stroke (mm)	980
Max Mold height (mm)	1000
Min Mold height (mm)	400
Space between tie bars(mm)	980*950
Ejector force (KN)	185
Ejector stroke (mm)	260
Others
Pump pressure (Mpa)	16
Motor/driving power (KW)	37+30(39.5+36.7)
Heating power (KW)	56.7
Machine dimension (M)	10.8*2.3*2.9
Machine weight (T)	42
Oiltank cubage (L)	1600

FAQ
Ningbo Union Power Machinery Co., Ltd.
Welcome to Ningbo Union Power Machinery Co., Ltd. Are you looking for high-quality injection molding machines? Look no further! At Ningbo Union Power Machinery Co., Ltd., we offer a wide range of customized machines designed for efficiency and stable performance.
Key Features:
Customized machines tailored to your products
18 months warranty for components
24-hour online support and technical assistance
Experienced technicians for installation and training
Turnkey projects including plant design and mold installation
Benefits:
Short cycle time for higher production
Cost-effective solutions with full machine testing
Efficient after-sales service for customer satisfaction
Increased profitability with high-performance machines
Contact us today for a quote and let us help you streamline your production process with our top-of-the-line injection molding machines!

---
