| Motor speed | 1800r/min |
| Milling motor power | 3kw |
| Drilling motor power | 1.5kw |
| Drilling and milling running method | Three-axis linkage |
| Control method | Servo motor |
| XYZ axis servo motor power | 2.25kw |
| Lateral travel (X axis) | 3000mm |
| Longitudinal travel (Y axis) | 3000mm |
| Vertical travel (Z axis) | 300mm |
| X axis running speed | 0-80m/min |
| Y axis running speed | 0-75m/min |
| Z axis running speed | 0-75m/min |
| Workbench Working angle | 0 degree,+90degree |
| Drilling tool size | Re32-φ8mm |
| Cooling method | Automatic spray |
| Voltage | 3phase |
| Processing size | 160x160x800mm |
| Working pressure | 0.6-0.8mpa |
| Measure | 1950x1350x1900mm |
| Weight | 430kg |
| Processing specialty | One-time clamping , processed on both sides |
