China-Made Stainless Steel Cryogenic Tank

Product Description

Captivating Descriptions ofAdvanced Cryogenic Storage Tank Solutions
NOBLEST Cryogenic Storage Tank series products are expertly crafted for diverse applications, including metal processing, medical technology, electronics, water treatment, energy generation, and the food industry. Today, industrial gases are delivered in liquid form at cryogenic temperatures, allowing for efficient storage and future use. NOBLEST proudly offers cryogenic tanks for the following liquefied gases:
Liquid nitrogen (LN)
Liquid argon (LAr)
Liquid oxygen (LOX)
Liquid carbon dioxide (LCO2)
Liquid natural gas (LNG)
Liquid nitrous oxide (LN2O)
The cryogenic tanks provided by Noblest are vacuum-insulated and available in both vertical and horizontal installations. Constructed with stainless steel inner vessels and piping, they ensurecomplete cleanliness and purity.
The exterior shell is treated with sandblasting, purging, and spraying and is specially coated withanti-corrosion paintto guarantee exceptional insulation quality.
We also offer customized cryogenic storage tanks with volumes up to 200m3 or higher based on end-user demand. We often supply complete equipment suites in industrial gas skids or gas evaporator stations, including vaporizers, pressure regulating and metering skids, buffer tanks, combined pressure regulating devices, PLC control systems, and more.
Specifications:

Design Temperature:	-196ºC~50ºC
Volume:	2~250m3 or Customized
Medium:	Liquid oxygen,argon,nitrogen,LNG,CO2,ethylene,etc
Working pressure:	0.2~3.5Mpa or customized
Placement Type:	Vertical or Horizontal
Certification:	ASME, GB150,CE
Insulation Method:	Vacuum powder/ Polyurethane foam/ High vacuum winding
Brand:	NOBLEST
Lead Time:	30 working days
Material:	Stainless steel / Carbon steel

Advantages:
★
Our tanks utilize a high vacuum winding insulation design and advanced high-efficiency vacuum
maintenance
technology, resulting in superior heat insulation and minimal liquid evaporation.
★
The body features a large diameter design and low vertical transport height, ensuring optimal performance and cost savings during transportation.
★
Its compact main structure requires minimal footprint and allows for fast and convenient installation.
★
The pipe layout is orderly and clear, with the tank's top designed using a whole forging welding structure to prevent gas or liquid leakage due to thermal expansion and contraction.
★
Optional
flow meters
and remote monitoring capabilities enable digital and information management.

---
