Automatic Bridge Type Marble and Granite Stone Polishing Machine

Product Description

Features:
This machine is mainly applied to grind and polish marble and granite slabs. It is mainly suitable for coarse grinding, fine grinding and polishing marble and granite slabs. Being pendulum which is advanced internationally now days, the grinding heads are controlled by air cylinder to elevate. Their longitudinal and transverse movements are enabled by cyclical pinwheel reduction motor. Having a PC programmer inside the electrical cabinet, it can grind the slabs in the way of longitudinal wave, transverse wave and cycle wave. Therefore, it features low cost and high grinding efficiency.
Technical Data:

Name	Unit	QSM-110	QSM-200
Max. processing size	mm	3000*1100	3200*2000
Max. thickness of slabs	mm	60	60
No. of grinding heads	pc	1	1
Lateral running speed of grinding head	Mm/min	3780	3780
Lateral running speed of working table	Mm/min	3300	3300
Main motor power	kw	11	11
Overall dimension(L*W*H)	mm	4500*2400*2100	4500*4340*2420
Total weight	kg	2700	4200
Air consumption	m³/min	0.1	0.1

---
