| Name | Unit | Parameter | |
| Travel | Three axis travel | mm | 1200/750/700 |
| Distance from spindle end face to worktable center | mm | 150~850 | |
| Worktable | Worktable Size(L×W) | mm | 1300×700 |
| Maximum load-bearing capacity of worktable | kg | 1200 | |
| T-shaped slot (width × spacing × quantity) | mm | 18×150×5 | |
| Spindle | Spindle diameter Spindle bore taper | ∅150/BT40 | |
| Max. spindle speed | rpm | 12000 | |
| Motor power | kW | 11/18.5 | |
| Feed Speed | Three axis fast moving speed(X/Y/Z) | m/min | 30/30/24 |
| Three axis feed speed | m/min | 10/10/10 | |
| Magazine | Magazine capacity | 24 | |
| Max tool diameter/length/weight | ∅75mm/300mm/7kg | ||
| Maximum tool diameter (full tool/adjacent empty tool) | mm | 75/150 | |
| Tool exchange time (T-T) | s | 1.8 | |
| Accuracy | (X/Y/Z) Positioning accuracy | mm | 0.01 |
| (X/Y/Z) repositioning accuracy | mm | 0.006 | |
| Others | Air source/pressure | 280L/min 6~8 Bar | |
| Total electrical capacity | KVA | 30 | |
| Water Tank Volume | L | 330 | |
| (X×Y×Z)Machine size (X×Y×Z) | mm | 3500×3600×3400 | |
| Estimated weight | kg | 8300 | |
