Machine parametersMachine Features 1. Hot air circulation system, high efficiency, drying food evenly.2. Temperature control and timer function, set the temperature and timer as needed.3. Adjustable temperature 0~100 degrees.4. It is easy to operate and clean, with high energy efficiency and retention of food nutrients.5. The movable drying tray can freely match the height of dry food to meet the needs of air-drying size.6. It is suitable for food industry, fruit and vegetable industry, chemical industry and medicinal materials and other industries, with a wide range of applications.Model numberProduction volumeElectricitysteamDrying carBakewareAir volumeMachine size (mm)Working size (mm)MS-48120KG/batch12KW20M²2 car483500m³/H2500*1220*22001700*1000*1430MS-96240KG/batch12KW20M²2 car963500m³/H2500*1220*22001700*1000*1430MS-144360KG/batch30KW80M²6 car14410500m³/H3500*2220*22002640*2000*1430MS-192480KG/batch45KW100M²8 car19214000m³/H4600*2220*22003580*2000*1430Machine introductionThis machine is made of low noise and high temperature resistant axial flow fan and automatic temperature control system. The entire circulation system is completely closed, which increases the thermal efficiency of the dryer from the traditional 3%-7% to 35%-45%. The highest thermal efficiency can reach 50%. Save more energy and increase economic benefits.Muls oven will make every piece for you https://moores.en.china.cnDevice name:ovenSpecificationscustom madeBlower power:4*1100W/380Vrange of working temperature:Room temperature +10~180℃Use voltage:380V/N+1+地/50HZTemperature control accuracy:±1℃heating power:32KW/min 1 gear controlTemperature uniformity:±3℃ (no-load test)Internal configuration:custom madeAdapt to the industry:extensiveStudio size:2000*2000*1500D*W*H(mm)Approximate size:2200*2400*1900D*W*H(mm)Machine structure overview:This product adopts the air outlet on both sides and the top return air circulation. The heating element is installed in theairduct on both sides of the box. The circulating motor is installed in the air duct on the top of the box, which can prolong thelife of the motor. The double doorand the door buckle are fixed with a claw handle.Box outer wall material:1.2mm DC01 carbon steel cold rolled sheet sheet metal bending welding rivet splicingBox air panel material1.2mm SUS304 stainless steel sheet metal bending machine punchingBox air duct material1.0mm SUS304 stainless steel sheet metal bending welding rivet splicingAir supply method:Strong pressure circulating airDoor frame sealing material:High temperature resistant foamed silicone rubber strip compression seal (if the operating temperature exceeds 250 ℃, use aluminumsilicate fiber rope)Temperature control instrument:LED LCD screen intelligent digital display temperature controller, temperature control accuracy ±1℃, with PID adjustment,automatic temperature control and constant temperatureIf your baked goods contain volatile gas or corrosive objects, please explain in detail with our technical service personnel, andinstall explosion-proof devices or use explosion-proof electrical appliances if necessary.It is strictly forbidden to directly bake flammable and explosive items! ! !If you need more detailed parameter information and a single product quotation, please contact the technical specialist: +8617760270259Can be designed and customized according to customer product needsOr send an email to Email: info@hnmoores.comWe will reply within 24 hours!Thank you for your interest in our products and look forward to working with you!Factory floorOur factoryHenan Moorse Machinery Co., Ltd. (hereinafter referred to as MS), established for more than 30 years, is committed to the development and manufacturing of various fruit and vegetable processing machinery, snack processing machinery, nut and meat processing machinery and their production lines The modern standard factory building covers an area of more than 18,000 square meters; MS has more than 50 professional engineers from different technical backgrounds with many years of rich research and manufacturing experience. All our products are made of high-quality stainless steel, with mature product design and sophisticated production technology. Therefore, high-quality products are easier to gain good market reputation and share. Our products are exported to the United States, Canada, Britain, France, Australia, South Korea, India, Singapore, Thailand, Malaysia, Sri Lanka, Brazil, Russia, Uzbekistan, Romania, Croatia, Latvia, Sweden, Nigeria, South Africa, etc. MS believes in the business philosophy of customer first and the concept of "quality first, worry-free after-sales", so MS focuses on providing customers with high quality, competitive prices and good service. Welcome to visit us and start cooperation!CertificatePackaging And LogisticsFAQQuestion 1: What are your advantages compared with your competitors?Answer:With rich industry experience and strict Product Quality Control systems, we provide:1). Stable and reliable product at reasonable price2). Good customer service: Fast response to any inquiry or question3). On-time delivery.Question 2: What are your Price Terms?Answer: Price can be based on FOB, CFR, or CIF, etc.Question 3: What are your modes of transportation?Answer: Courier service, Air transport, Sea Transport.Question 4: How to guarantee your machines quality?Answer: We choose safe and good quality raw material and set up professional QC department to check quality and details during production. Question 5 :How to ship the machine?Answer: The machines will be delivered by express, air or sea transportation according to your requirement.Question 6: What’s your after-sales service?Answer: First,every machine has one year warranty.And,there are engineers on-site installation and maintenance when necessary.Last,we will keep touching and offer feedback on time if you have questions after buying.
>>
