Ck6140 CNC Lathe with Hydraulic Chuck 8 Station Power Turret

Product Description

CK6140 CNC Lathe with Hydraulic Chuck 8 Station Power Turret
Product Picture:
CNC Lathe Machine Characteristics:
CNC machine tool is the abbreviation of digital control machine tool, which is an automatic machine tool with program control system. The control system can logically process and decode the program with control code or other symbolic instructions to cause the machine to operate and machine the part.
Compared with ordinary machine tools, CNC machine tools have the following characteristics:
High processing precision and stable processing quality;
Multi-coordinate linkage can be performed to process parts with complex shapes;
When the machined parts are changed, generally only need to change the NC program, which can save production preparation time;
The machine tool itself has high precision and rigidity, and can choose favorable processing amount, and the productivity is high (usually 3~5 times of ordinary machine tools);
The degree of automation of the machine tool is high, which can reduce the labor intensity;
Application:
CNC lathes are one of the most widely used CNC machine tools. It is mainly used for the inner and outer cylindrical surfaces of shaft parts or disc parts, the inner and outer conical surfaces of any taper angle, the complex inner and outer curved surfaces, the cylindrical and conical threads, etc., and can be used for grooving, drilling, reaming and reaming. Holes and pupils, etc.
CNC Lathe Machine Technical Parameters:

Specifications	Unit	CK6140
Max.swing over bed	mm	Ф400
Max.swing over cross slide	mm	Ф180
Distance between centers	mm	1000/1500
X/Z axis travel	mm	X:220 Z:1050/1600
Spindle transmission type		Mechanical 2 gear transmission ,in gear variable speed
Spindle speed steep		variable
Spindle speed	rpm	L:70~560,H:200~1600
Spindle nose		C6
Thru-hole dia.of spindle	mm	52
Spindle taper		MT6
Spindle motor	KW	5.5
Chuck size	mm	200
Ball screw dia.and pitch	mm	φ25X6/φ40X8
X/Z axis feed motor torque	N.m	X:6 Z:10
X/Z axis feed motor power	KW	X:1.5 Z:2.5
X/Z axis fast moving speed	mm/min	X:6000 Z:8000
X/Z axis Position accuracy	mm	0.02/0.025
X/Z axis repeatability	mm	0.01/0.015
Processing accuracy		IT6-IT7
Workpiece surface roughness		Ra1.6
Tailstock sleeve dia.	mm	65
Tailstock sleeve travel	mm	140
Tailstock sleeve taper	#	MT4
Guide form		Spindle mountain+flat rail
Total power capacity	KVA	10
Machine dimension(L×W×H)	mm	2500/3000X1500X1650
N.W.	kg	1800/2300

Brand Image:
As a professional manufacturer of lathe machines, we want our customers to know of our commitment to providing the latest products to all customers.
CNC Lathe Machine Details:
CNC Lathe Machine Package Delivery:
---->We can guarantee on-time delivery
---->Packing: The machine and accessories are fixed in the wooden box, then spray anti-corrosion oil, hang up the desiccant to ensure the safety of the machine during long-term transportation.
---->Export case: wooden box with Tito, two, fumigation wooden box,
---->Mode of transport: transported by sea or rail to the customer's location.
Our CNC Lathe Machine Workshop:
Our Compan:
FAQ
1. What level of service do you provide ?
--->Your inquiry will be replied within 24 hours.
2. Technology support by providing operation?training videos?
---->Professional after-sales service team.
We can Provide Technical support online service and Machine operation Vedio
We can provide on-site training and commissioning Vedio
We can Provide Spare parts replacement and repair service
Give reasonable offers with the best quality.
3. What is our advantages?
----> Competitive price: We can meet your budget and best-selling business very well.
OEM Accepted: We can produce customized design.
Good Service: We treat clients as friends and provide problem solving anytime you need.
Good Quality: We have strict quality control system. Good reputation in the market.
Fast & Delivery: We have big discount from forwarder (Long-term Contract).
4. Can you customize the machine for the customer?
---->Yes. We can, if you need customized services, please contact us
5. What is the MOQ?
---->We usually provide 1 set for customers to test.
6.What is your delivery time?
---->The delivery depends on different machines with different configurations. Please contact us to confirm it is in stock or not.
7.What is your payment method?
---->We prefer to do 100% T/T (30% T/T in advance, 70% T/T before shipment)
8.Agents Wanted:
---->We have strong partnerships in Europe, America, South America, India, Southeast Asia and South Africa. We also supply OEM service, and we are looking for agents in these areas. In the further, we want to develop SCHULER to a global brand. Wherever you are from, we are looking forward to explore new market with you.
If any questions pls feel free to contact me
Contact information :
Shangdong Schuler Machinery Tool Co,Ltd.
Add: Tengzhou City ,Shandong Province ,China
Edwin
Mob: +86-18663288651

---
