Product Details
Product Description
Product Description
Focus on DCS, PLC, robot control system and large servo system.
Main products: various modules / cards, controllers, touch screens, servo drivers.
Advantages: supply of imported original products, professional production parts,
Fast delivery, accurate delivery time,
The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands
Group 13
ANALOGUE INPUTS
1301 MINIMUM AI1 0-100 % 1 %
1302 MAXIMUM AI1 0-100 % 1 %
1303 FILTER AI1 0-10 s 0.1 s
1304 MINIMUM AI2 0-100 % 1 %
1305 MAXIMUM AI2 0-100 % 1 %
1306 FILTER AI2 0-10 s 0.1 s
Group 14
RELAY OUTPUTS
1401 RELAY OUTPUT 1 0 = NOT SEL
1 = READY
2 = RUN
3 = FAULT (-1)
4 = FAULT
5 = ALARM
6 = REVERSED
7 = SUPRV1 OVER
8 = SUPRV1 UNDER
9 = SUPRV2 OVER
10 = SUPRV2 UNDER
11 = AT SET POINT
1
1402 RELAY OUTPUT 2 0-11, see 1401 RELAY OUTPUT 11
Group 15
ANALOGUE OUTPUT
1501 AO CONTENT 102-130 1
1502 AO CONTENT MIN x-y z
1503 AO CONTENT MAX x-y z ä
1504 MINIMUM AO 0.0-20.0 mA 0.1 mA
1505 MAXIMUM AO 0.0-20.0 mA 0.1 mA
1506 FILTER AO 0-10 s 0.1 s
Group 16
SYSTEM CONTROLS
1601 RUN ENABLE 0 = NOT SEL
1...5 = DI1...DI5
6 = COMM
1 ä ä
1602 PARAMETER LOCK 0 = LOCKED
1 = OPEN
2 = NOT SAVED
1
1604 FAULT RESET SEL 0 = KEYPAD ONLY
1...5 = DI1...DI5
6 = START/STOP
7 = COMM
1 ä
Group 20
LIMITS
2003 MAX CURRENT 0.5*IN - 1.5*IN 0.1 A
2005 OVERVOLT CTRL 0 = DISABLE
1 = ENABLE
1
2006 UNDERVOLT CTRL 0 = DISABLE
1 = ENABLE (TIME)
2 = ENABLE
1
2007 MINIMUM FREQ 0-250 Hz 1 Hz
2008 MAXIMUM FREQ 0-250 Hz 1 Hz ä ä
Code Name Range Resolution S M
37
APPENDIX
Group 21
START/STOP
2101 START FUNCTION 1 = RAMP
2 = FLYING START
3 = TORQUE BOOST
4 = FLY + BOOST
1
2102 STOP FUNCTION 1 = COAST
2 = RAMP
1
2103 TORQ BOOST CURR 0.5*IN - 2.0*IN 0.1 A
2104 STOP DC INJ TIME 0-250 s 0.1 s
2105 PREMAGN SEL 0 = NOT SEL
1...5 = DI1...DI5
6 = CONST
1 ä ä
2106 PREMAGN MAX TIME 0-250 s 1 s
Group 22
ACCEL/DECEL
2201 ACC/DEC 1/2 SEL 0 = NOT SEL
1...5 = DI1...DI5
1 ä ä
2202 ACCELER TIME 1 0.1-1800 s 0.1 s
2203 DECELER TIME 1 0.1-1800 s 0.1 s
2204 ACCELER TIME 2 0.1-1800 s 0.1 s
2205 DECELER TIME 2 0.1-1800 s 0.1s
2206 RAMP SHAPE 0 = LINEAR
1 = FAST S CURVE
2 = MEDIUM CURVE
3 = SLOW S CURVE
1
Group 25
CRITICAL FREQ
2501 CRIT FREQ SEL 0 = OFF
1 = ON
1
2502 CRIT FREQ 1 LO 0-250 Hz 1 Hz
2503 CRIT FREQ 1 HI 0-250 Hz 1 Hz
2504 CRIT FREQ 2 LO 0-250 Hz 1 Hz
2505 CRIT FREQ 2 HI 0-250 Hz 1 Hz
Group 26
MOTOR CONTROL
2603 IR COMPENSATION 0-30 V 1 ä
2604 IR COMP RANGE 0-250 Hz 1 Hz ä
2605 LOW NOISE 0 = STANDARD
1 = LOW NOISE
1 ä
2606 U/f RATIO 1 = LINEAR
2 = SQUARE
1 ä
Group 30
FAULT FUNCTIONS
3001 AI
1 = FAULT
2 = CONST SPEED7
3 = LAST SPEED
1
3002 PANEL LOSS 1 = FAULT
2 = CONST SPEED7
3 = LAST SPEED
1
3003 EXTERNAL FAULT 0 = NOT SEL
1...5 = DI1...DI5
1
Code Name Range Resolut
