| Diesel Generator | SP3500DSE | SP5000DSE | SP6500DSE | SP7500DSE | SP8500DSE | SP9500DSE | SP10500DSE | SP11500DSE |
| Rated frequency(HZ) | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 |
| Rated voltage(V) | 220.230.240.110/220.120/220.120/240.220/380.230/400 | |||||||
| Max power(KW) | 3 | 4.6 | 5 | 5.5 | 6.5 | 8 | 10 | 10.5 |
| Rated power(KW) | 2.8 | 4.2 | 4.5 | 5 | 6 | 7.5 | 9 | 10 |
| Alternator | Copper | Copper | Copper | Copper | Copper | Copper | Copper | Copper |
| Factor | 1/0.8 | 1/0.8 | 1/0.8 | 1/0.8 | 1/0.8 | 1/0.8 | 1/0.8 | 1/0.8 |
| Phase | Single phase/Three phase | |||||||
| Starting system | Electric start | Electric start | Electric start | Electric start | Electric start | Electric start | Electric start | Electric start |
| Fuel tank volume(L) | 15 | 15 | 15 | 15 | 15/30 | 15/30 | 30 | 30 |
| Model | SP178F(E) | SP186F(E) | SP186FA(E) | SP188F(E) | SP192F(E) | SP1100F(E) | SP1102FE | SP1103FE |
| BoreXstroke(mm) | 78*62 | 86*70 | 86*72 | 88*75 | 92*75 | 100*84 | 110*84 | |
| Displacement(cc) | 296 | 406 | 418 | 456 | 498 | 660 | 720 | 760 |
| Compression ratio | 20:01 | 19:01 | 19:01 | 19:01 | 19:01 | 19:01 | 19:01 | 19:01 |
| Type | Single Cylinder, Air Cooled, 4-stroke,Diesel engine. | |||||||
| Ignition system | Compression combustion | |||||||
| Noise level(dB) | 72 | 72 | 72 | 72 | 72 | 72 | 72 | 72 |
| G.W.(kg) | 142 | 152 | 155 | 158 | 163 | 280 | 300 | 320 |
| Dimension(mm) | 950*530*700 | 950*530*700 | 950*530*700 | 950*530*700 | 950*530*700 | 1180*600*800 | 1180*600*800 | 1180*600*800 |
