Product Details
Product Description
Product Description
Ribbon Blender
Introducing the versatile workhorse of the mixing world – the Ribbon Blender, also referred to as the Ribbon Mixer. With its cylindrical shape and double helix ribbon agitator, this industrial-grade equipment is engineered to effortlessly combine powders, granules, and various dry materials, delivering a homogenous blend that meets even the most exacting standards of quality and consistency.
The apparatus comprises a U-shaped container featuring a dual helix ribbon mixer, which revolves within the container. The mixer includes both an inner and outer helix, which work in opposing directions to generate a delicate yet comprehensive blending effect on the materials.
screw mixer
small powder mixer
powder mixing equipment
Adaptable: Ribbon blenders exhibit exceptional mixing capabilities, effortlessly blending a diverse array of materials, ranging from powders and granules to pellets and flakes, thus catering to a myriad of applications with unparalleled versatility.
Dual-directional mixing: The ribbon blades move the materials both radially and laterally, resulting in a more thorough and uniform mixing of the ingredients.
Hygienic design: Some ribbon blenders are designed with features that allow for easy cleaning and sanitation, making them suitable for use in the food, pharmaceutical, and cosmetic industries.
Batch consistency: Provide consistent batch-to-batch results, making them suitable for applications that require precise mixing ratios.
Safety features: The machine comes equipped with safety features such as interlocks and guards to prevent accidents and ensure operator safety.
Tailoring: The equipment can be tailored with a myriad of options, such as adjustable speed drives for meticulous regulation, and diverse ribbon agitator configurations for targeted tasks.
INDUSTRIES AND APPLICATIONS
FOOD INDUSTRY
Ribbon blenders are the culinary artisans’ favorite tool to mix a medley of dry ingredients, including fragrant spices, flour, sugar, and other food powders. They are adept at combining dry and wet ingredients to create delectable sauces, pastes, and other mouth-watering culinary delights.
PHARMACEUTICAL INDUSTRY
The pharma industry swears by the prowess of ribbon blenders in mixing dry powders and granules to produce tablets, capsules, and other life-saving drug products. These mixers work wonders in blending various formulations of drugs to yield a uniform and consistent mixture.
CHEMICAL INDUSTRY
Ribbon blenders are the go-to mixing equipment for the chemical industry, where they are used to blend dry powders and granules to make fertilizers, pesticides, and other chemical products. These versatile machines also excel in combining different formulations of chemicals to create a seamless blend.
COSMETICS INDUSTRY
Create a variety of high-quality cosmetics, including face powders, eyeshadows, and blushes. These blenders can effortlessly blend dry powders and granules, creating smooth and silky cosmetics. Additionally, they can blend different formulations of cosmetics, ensuring a consistent and reliable mixture.
PLASTICS INDUSTRY
Ribbon blenders are the go-to apparatus for amalgamating dry powders and granules, forming a cohesive compound. Additionally, they are employed to blend diverse plastic formulations, ensuring a consistent and well-blended final product.
TECHNICAL SPECIFICATION
Model
| Volume(L)
| Voltage
| Speed
(r/min)
| Power(kw)
| Dimension(mm)
| Weight(kg)
|
RB-10
| 10
| 220V
| 50
| 1.5
| 550*300*600
| 35
|
RB-30
| 30
| 220V
| 50
| 2.2
| 670*360*770
| 46
|
RB-50
| 50
| 220V
| 50
| 2.2
| 770*430*800
| 56
|
RB-100
| 100
| 220V
| 50
| 1.6
| 1400*550*1000
| 140
|
RB-200
| 200
| 220V
| 50
| 2.2
| 1630*660*1150
| 180
|
RB-300
| 300
| 380V
| 50
| 3
| 1750*750*1350
| 250
|
RB-500
| 500
| 380V
| 40
| 4
| 1950*800*1480
| 300
|
RB-600
| 600
| 380V
| 40
| 5.5
| 2100*850*1500
| 500
|
RB-1000
| 1000
| 380V
| 35
| 11
| 2900*1000*1700
| 800
|
RB-2000
| 2000
| 380V
| 30
| 18
| 3450*1250*1900
| 1400
|
RB-3000
| 3000
| 380V
| 30
| 22
| 4400*1300*2000
| 2200
|
>>
