IntroductionThe LED dust sensor PM1009 adopts the infrared correlation principle, can accurately measure 4-channel particle count for different particle size for 10μm-60μm, 60μm-180μm, 180μm-500μm and >500μm which pass through vacuum cleaner's vacuum pipe or vacuum extension rod pipe, etc.
Features1.Easy integration to customer device;
2. 4-channel particle count output for different particle size range: 10μm-60μm, 60μm-180μm, 180μm-500μm and 500μm;
3.Quick response;
Specifications
| Operating principle | LED infrared |
| Measurement range | 0-10000pcs |
| Measurement channel | 10μm-60μm, 60μm-180μm, 180μm-500μm, 500μm |
| Response time | 0.5s |
| Working temperature | -10~60℃; 0~95%RH (non-condensing) |
| Storage temperature | -20~80℃; 0~95%RH (non-condensing) |
| Power supply | DC 3.3V±5%, ripple <50mV |
| Working current Average | <60mA |
| Signal output UART | 3.3V level |
| Dimension | Main control PCBA ( L26.5*W16.0*H1.0 mm)
Transmitter & receiver board(L20 *W10.56 mm) |
Note 1:
- Vibration mitigation measures such as rubber gaskets should be taken to avoid vibration when installing the transmitting and receiving parts;
- The fixed installation should be 180° between the transmitting part and receiving part;
- The distance between transmitting part and receiving part should be less than or equal to 60mm;
- When dust contaminates the lens of receiving part,it can be wiped by medical cotton swab soaked in water and then with a dry swab to wipe it again.Do not use alcohol.
ApplicationsHousehold Vacuum Cleaner
>>
