Ribbed Cleat Rubber Conveyor Belt

Product Description

Ribbed cleat rubber conveyor belt
Top 5 conveyor belt manufacture in china
Huayue V-Shape Chevron Patterned Conveyor Belt Competitive Advantage
L Plies: 1-10ply
L width (BW): 400-1400mm
L Thickness: 4-30mm
L Pattern pitch(CW): 125mm-500mm
L Type: Open V close V, Ltype, H type, Utype, multi-Vtype, etc.
L Height of pattern(CH): 5 mm, 10mm, 15mm, 17mm, 25mm, 32mm.
L Pattern can be designed according to the customers' requirement.
L Abrasion resistant & High Tensile Strength
L ISO9001: 2008, SGS, Bureau Veritas Certificate.
L More Than 30 years professional experience. (Since 1982)
L International Standard: DIN, BS, AS, RMA, AS, JISK, SABS etc
Features:
1. Can carry loose materials at angle of 17-18 and bagged material at 30-35
2. Cleat angle and pitch are designed for smooth travel over return idlers
3. Cleats and the top cover rubber are mono block molding for strength
Application:
There are open type and closed type, suitable for bulk or bagged materials such as powder and granule with incline less than 45 C.
Patterned conveyor belt are used primarily when the angle of incline becomes too steep for a smooth conventional conveyor belt. The belt is fitted with integrally moulded cleats which prevent the material from sliding backwards as would be the case with a smooth surface belt. Different cleat designs allow the carrying of many types of material, from bulk solids to unit loads.
Technical Data of Rubber Cover:
Ensile Strength: ≥ 10Mpa
Elongation at Break: ≥ 350%
Adhesive strength between carcass: ≥ 6.0N/mm
Adhesive strength between cover and carcass: ≥ 3.0N/mm
Elasticity: ≥ 32%
Abrasion: ≤ 200mm3
About Huayue Company
Huayue is the Top 5 manufacturers and exporters of Conveyor Belt in China. Our range of conveyor belts are highly appreciated by our clients due to its heat resistance feature and other availability in various sizes and designs. These are dimensionally accurate as per international standards.
Our best quality based on:
Manufacturer
Experience in Cooperate with Fortune 500 Companies
Professional Engineering Capability
Stable Quality
Reasonable Price
Small Orders Accepted
Continuous Improvements
High Product Performance
Prompt Delivery
Professional Service
For more details, please inquiry us!
Polyester conveyor belt, (EP)
Nylon conveyor belt, (NN)
Cotton conveyor belt, (CC)
Sidewall conveyor belt (SW)
Steel Cord conveyor belt ( ST )
Chevron conveyor belt, (C5 C10 and C15)
Oil Resistance conveyor belt, (OR and MOR)
Hot Resistance conveyor belt, (HR)
Fire Resistance conveyor belt, (FR/PVC/PVG)
Heat Resistance conveyor belt, (HR/ FR)
Cold Resistance conveyor belts, (CR)
Pattern conveyor belt ( 30+ Moulds)
Metal Mesh conveyor belt (Heat resistant temp until 800c)
Endless belts
Conveyor roller, idler
Conveyor Pulley, frame, bracket etc

---
