Gold Mine Mining Equipment, Gold Ore Dressing Production Line

Product Description

Beneficiation gold equipment with reasonable design
Mature technology,
Reasonable design, accurate manufacture,
High-efficient performance,
Give you the plant you wanted.
Production Process Introduction
After coarse crushing, fine crushing and screening, mined ores are crushed to the required particle size. Crushed ores then goes into grinding equipment such as ball mill, rod mill, and classifying equipment, for example, spiral classifier, in order to enable mineral particles reach the required granularity. Qualified ore powder will be separated by flotation machine, magnetic separation machine and other separating equipments. In the screening process, qualified concentrate powder will be selected, and the tailings will be sorted out. Fine ore powder goes into thickener and filtration equipment for dehydration, meeting the requirements for transportation and smelting.
Main Equipments for Ore Dressing
ZSW series vibrating feeder, jaw crusher, DTIIfixed belt conveyor, YA series circular vibrating screen, GZ series electromagnetic vibrating feeder, FC/FG spiral classifier, ball mill for ore dressing, XCF/KYF type mechanical agitation flotation machine and so on.
Company Name: Henan Zhengzhou Mining Machinery Co., Ltd.
Official Website: http://hnzkjq.en.made-in-china.com
24-hour Free Sales Consulting Phone: 861-0371 -5590 2866.
Company Address: Qiaolou caizhai industrial estate, Xingyang city, Henan Province
Please pay attention to the company's other products:
Price of rotary kiln: http://hnzkjq.en.made-in-china.com/calcining.html
Rotary Kiln:http://hnzkjq.en.made-in-china.com/calcining.html
Preheater: http://hnzkjq.en.made-in-china.com/calcining/8.html
Cement Mill: http://hnzkjq.en.made-in-china.com/grinding/17.html
Rotary Dryer: http://hnzkjq.en.made-in-china.com/calcining/116.html
Raw Mill: http://hnzkjq.en.made-in-china.com/grinding/16.html
Trommel Screen:http://hnzkjq.en.made-in-china.com/separating/137.html
Rotary cooler:http://hnzkjq.en.made-in-china.com/calcining/6.html

Metallurgy, mineral processing ball mill
model	cylinder rev(r/min)	grind media weight	feeding size(mm)	output size(mm)	output	motor
		(t)			(t/h)	type	power
MQG900X1800	38	1.8	≤ 25	0.074-.06	0.8-1	Y255M-8	22
MQG900X3000	37.4	2.7	≤ 25	0.074-0.3	0.8	Y225M-6	30
MQG1200x2400	32	4.8	≤ 25	0.074-.06	1.5-2	Y280M-8	45
MQG1200X4500	30	5.2	≤ 25	0.074-.06	1.5	Y280M-6	55
MQG1500x4500	28.8	10	≤ 25	0.074-0.4	3-4	JR126-8	110
MQG1500x5700	28.8	12	≤ 25	0.074-0.4	3-5	JR127-8	130
MQG1500x6400	28.8	13	≤ 25	0.074-0.4	3-5	JR127-8	130
MQG1830x5400	24.5	15	≤ 25	0.074-0.4	5-7	JR137-8	210
MQG18306400	24.5	19	≤ 25	0.074-0.4	5-7	JR137-8	210
MQG1830x7000	24.5	20	≤ 25	0.074-0.4	6-8	JR138-8	245
MQG2200x7000	21.6	30	≤ 25	0.074-0.8	8-10	JR158-8	380
MQG2200x9000	21.4	34	≤ 25	0.074-0.8	8-10	JR1510-8	475
MQG2400x7000	20.4	36	≤ 25	0.074-0.8	10-14	JR1510-8	475
MQG2400x8000	20.4	42	≤ 25	0.074-0.8	10-14	YR630-8	560
MQG2600x8000	19.6	52	≤ 25	0.074-0.8	16-20	JR1512-8	630
MQG3000x9000	18.3	78	≤ 25	0.074-0.8	20-25	YR1000-8/1180	1000

FAQ:
Q: Are you a factory or a trading company?
A: We are factory manufacturing packaging machines and we provide perfect OEM and after-sale service.
Q: Can you send me the video to show how the machine works?
A: Certainly, we have made video of every machine and uploaded them to Youtube.
Q: What should I take care when using the machine?
A: Keep the machine away from thinner and other chemical liquid.
Q: How to maintain the machine?
A: Check the connection part and clean the screen frame regularly.
Q: How can I pay my order?
A: We accept T/T, Western Union, ****** Trade Assurance payments. For those orders less than 1000USD, we accept PayPal to pay.
Q: Do you have a CE certificate?
A: For every model of machine, it has a CE certificate.
Packaging Detail :
The main machinery is in nude packing and spare parts in Wooden or steel box standard export packing, suitable for long distance delivery.

---
