4feet Integrated T5 LED Tube Batten Light

Product Description

Besturn lighting is integrated T5 LED tube manufacturers and trader in china, specialized in the research, development and production of LED T5 tube light.
Advantages of Integrated T5 LED Tube:
1.Integrated LED T5 tube light is with integrated hard-wired connector, easy to seamless connecting;
2.Can be continuous installation and easy installation;
3.Max.10Pcs continuous installation for 1200mm tube T5 light;
4.Integrated tube light T5 is with 300mm ~1200mm multi specification for your optional;
5.Adopts high quality LED chips with high efficiency 100Lm/w and CRI>75;
6.Three kinds of color temperature range from 3000K to 6500K for your choose;
7.Lamp body in high-quality steel bending and forming processes, with simple appearance, high mechanical strength.
8.Glass tube with patent inner nano-optical powder coating, >90% light transmittance, anti-UV & anti-diffuse and soft light;
9.Isolated constant current with steady output voltage;
10.More 40% energy saving than the traditional fixture;

Integrated T5 LED Tube Technical data:
- Material: High quality steel with white painting body and glass LED tubes

Code	TFB1906A-5	TFB1906A-7	TFB1906A-9	TFB1906A-10	TFB1906A-12	TFB1906A-14
LED chip	SMD	SMD	SMD	SMD	SMD	SMD
Power (W)	5w	7w	9	10w	12	14W
Color Temperature (K)	3000/ 4000/6500 K	3000/ 4000/6500 K	3000/ 4000/6500 k	3000/ 4000/6500 K	3000/ 4000/6500 k	3000/ 4000/6500 K
Voltage(V)	AC220~240v	AC220~240v	AC220	AC220~240v	AC220	AC220~240v
Lumen (lm)	500lm	700lm	900	1000lm	1200	1400 lm
CRI (Ra)	>75	>75	>70	>75	>70	>75
Size (mm)	292×25 ×37mm	572×25 ×37mm	772×25 ×37mm	872×25 ×37mm	1072×25 ×37mm	1172×25 ×37mm
Driver	Inside	Inside	inside	Inside	inside	Inside
Package (PCS/CTN)	20	20	20	20	20	20

Integrated T5 LED Tube Installation Show
- Integrated hard-wired connector, seamless connection;
- Max. 10 pcs continuous connection for 1200mm T5 14w;

Integrated T5 LED Tube Packing Information
- Individual package and outer carton, 20Pcs for one package
- Professional and safe package ensure goods can safety arrive on our customers' side.
- We also customize package according to customers'requirement

For each specification packing details please refer to below sheet:
Integrated T5 LED Tube Application: be widely applied to indirection lighting, exhibition display lighting, advertisement indicating lighting etc.

Spec.	Model	Q'ty/Ctn	Size/1 Pcs (mm)	N.W.(KG)/ Ctn	G.W. (KG)/ Ctn	Length (cm)	Width (cm)	Height (cm)
300mm	TFB1906A-105	20	305x28x38	4.4	5.1	37.0	16.0	17.0
600mm	TFB1906A-107	20	585x28x38	6.4	7.35	65.0	16.0	17.0
800mm	TFB1906A-109	20	785x28x38	8.34	9.42	85.0	16.0	17.0
900mm	TFB1906A-110	20	885x28x38	9.66	10.8	95.2	16.0	17.0
1000mm	TFB1906A-112	20	1035x28x38	11.2	12.6	111.0	16.0	17.0
1200mm	TFB1906A-114	20	1185×28×38	12.2	13.85	125.0	16.0	17.0

Q: 1. Can I have a sample order for led light? A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q: 2. What about the lead time? A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than 5000pcs.

Q: 3. Do you have any MOQ limit for led light order? A: Low MOQ, 1pc for sample checking is available

Q: 4. How do you ship the goods and how long does it take to arrive? A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.

Q: 5. How to proceed an order for led light? A: Firstly let us know your requirements or application. Secondly We quote according to your requirements or our suggestions. Thirdly customer confirms the samples and places deposit for formal order. Fourthly We arrange the production.

Q: 6. Is it OK to print my logo on led light product? A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q 7: Do you offer guarantee for the LED light products? A: Yes, we offer 2-5 years warranty to our products.

Q 8: How to deal with the faulty led lights? A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%. Secondly, during the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.

---
