Atess 150kw Solar System Three Phase PV Grid Tied Power Inverter for Solar System

US$1,338.00
2-9 Pieces
US$1,298.00
10-49 Pieces
US$1,208.00
50+ Pieces

Basic Info.

Model NO.
ATESS-HPS150KW
Nature of Source Flow
Active Inverter
Phase
Single
Output Power
8000W
Certification
SAA, CE, ROHS, ISO9001, CCC
Brand
Deye
Type
DC/AC Inverters
Power Source
Solar Power
Circuit Topologies
Full-Bridge Type
Nature of Wave String
Sine Wave Inverter
MPPT Voltage Range (V)
150-425
No. of Mpp Trackers
2
No. of Strings Per Mpp Tracker
2+2
Output Active Power (W)
7600
Output Voltage (V)
220/230
Output Frequency
50/60Hz
Battery Type
Lead-Acid or Lithium-Ion
Ingress Protection(IP) Rating
IP 65
Type of Cooling
Intelligent Air Cooling
Transport Package
Carton and Pallets
Specification
420W*670H*233D
Trademark
Deye
Origin
China
HS Code
8504403090

Product Description

Product Description
Product size display
Product composition display
Product accessories display
Product Parameters
Model HPS30 HPS50 HPS100 HPS150
AC (Grid-connected)
Apparent power 33kVA 55kVA 110kVA 165kVA
Rated power 30kW 50kW 100kW 150kW
Rated voltage 400V
Rated current 43A 72A 144A 217A
Voltage range 360V - 440V
Rated frequency 50/60Hz
Frequency range 45~55/55~65Hz
THDI <3%
AC connection 3/N/PE
AC input 60kVA 100kVA 200kVA 240kVA
AC(Off-grid)
Apparent power 33kVA 55kVA 110kVA 165kVA
Rated power 30kW 50kW 50kW 150kW
Rated voltage 400V
Rated current 43A 72A 144A 217A
THDU ≤2%linear
Rated frequency 50/60Hz
Overload capability 110%-10 mins, 120%-1 min
DC (Battery and PV)
Battery voltage range
at Max. charge power		 450V-600V 500V-600V 500V-600V 500V-600V
Battery voltage range 352-600V
Max. charge power 45kW 75kW 150kW 225kW
Max. discharge power 33kW 55kW 110kW 165kW
General Information
Protection degree IP20
Operating temperature -25 °C~+55 °C
Cooling Forced-air
Maximum altitude 6000m (derate over 3000m)
Dimension (W/H/D) 700/1660/600mm 950/1860/750mm 1200/1900/800mm 1200/1900/800mm
Weight 355kg 610kg 948kg 1230kg
