| Dimensions | |
| Overall Length for Transport (mm) | 9680 |
| Overall Width for Transport (mm) | 2980 |
| Overall Height for Transport (mm) | 3440 |
| Full Height of Cab (mm) | 3075 |
| Width of Upperstructure (mm) | 2875 |
| Ground Contact Length of Track (mm) | 3445 |
| Overall Length of Track (mm) | 4250 |
| Track Shoe Width (mm) | 600 |
| Track Gauge (mm) | 2380 |
| Minimum Ground Clearance (mm) | 440 |
| Minimum Swing Radius of Front Work Equipment (mm) | 3730 |
| Rear Swing Radius (mm) | 2900 |
| Maximum Height at Minimum Swing Radius (mm) | 7680 |
| Number of Carrier Rollers (per side) | 2 |
| Number of Track Shoes (per side) | 47 |
| Number of Support Rollers (per side) | 8 |
| Working Range | |
| Maximum Digging Radius (mm) | 10,280 |
| Maximum Digging Depth (mm) | 6,600 |
| Maximum Digging Height (mm) | 9,600 |
| Maximum Dumping Height (mm) | 6,730 |
