Ja Solar Tier 1 Brand Longi Solar Panel 420W for Home 405W 400W 550W 575watt Tina/Canadian/Jinko Panels

Product Description

Solar PV Module 565W PERC Mono Solar panel
High Quality&Efficiency Crystalline Silicon Cells: A grade solar cells
A Wide Range of Products:Mono-crystalline solar panel and poly(multi)-crystalline solar panel(depending on configurations)
High Reliability:Guaranteed mechanical resistance to severe weather conditions for reliable power output.Compliant with IEC 61215 and IEC61730.Certified by TUV,CE,ISO and etc.
Tight Tolerance:Guaranteed positive tol erance from 0-3% ebsures power ♦output reliability.
Traceability:We provide flash report and embedded bar code ID for each module for complete traceability
A Wide Range of Applications: Independent systems(household,powder supplies for remote areas, remote systems, ete.)and grid-connected photovoltaic power stations(residential,commercial, industrial power supply systems)
Warranty:10-year limited product warranty and 25-year limited power guarantee
Product Details

Product Specifications ELECTRICAL PARAMETERS AT STC TYPE JAM72S30 560/LR JAM72S30 565/LR JAM72S30 570/LR JAM72S30 575/LR JAM72S30 580/LR JAM72S30 585/LR Rated Maximum Power(Pmax) [W] 560 565 570 575 580 585 Open Circuit Voltage (Voc) [V] 50.32 50.50 50.68 50.86 51.04 51.22 Maximum Power Voltage(Vmp) [V] 41.49 41.68 41.87 42.05 42.24 42.42 Short Circuit Current(Isc) [A] 14.25 14.31 14.37 14.44 14.50 14.56 Maximum Power Current(Imp) [A] 13.50 13.56 13.62 13.67 13.73 13.79 Module Efficiency [%] 21.2 21.4 21.5 21.7 21.9 22.1 Power Tolerance 0-+3W Temperature Coefficient of Isc(a_Isc) +0.045%/C Temperature Coefficient of Voc (β_Voc) -0.275%/ºC Temperature Coefficient of Pmax(y_Pmp) -0.350%/C STC Irradiance 1000W/m², cell temperature25°C,AM1.5G Remark: Electrical data in this catalog do not refer to a single module and they are not part of the offer. They only serve for comparison among different module types. ELECTWRICAL PARAMETERS AT NOCT TYPE JAM72S30 560/LR JAM72S30 565/LR JAM72S30 570/LR JAM72S30 575/LR JAM72S30 580/LR JAM72S30 585/LR Rated Max Power(Pmax) [W] 424 428 431 435 439 443 Open Circuit Voltage(Voc) [V] 47.62 47.79 47.96 48.13 48.30 48.74 Max Power Voltage(Vmp) [V] 39.26 39.44 39.62 39.79 39.97 40.14 Short Circuit Current(Isc) [A] 11.40 11.45 11.50 11.55 11.60 11.65 Max Power Current(Imp) [A] 10.80 10.85 10.89 10.94 10.99 11.03 NOCT Irradiance 800W/m², ambient temperature 20°C, wind speed 1m/s,AM1.5G * For Nextracker installations, maximum static load please take compatibility approve letter between JA Solar and Nextracker for reference. OPERATING CONDITIONS Maximum System Voltage 1000V/1500V Operating Temperature -40ºC~+85ºC Maximum Series Fuse Rating 25A Maximum Static Load, Front* 5400Pa(112 lb/ft2) Maximum Static Load, Back* 2400Pa(50 lb/ft²) NOCT 45±2ºC Safety Class Class II Fire Performance Type1 Mechanical Specification: Cell Mono Weight 28kg Dimensions 2333±2mmx1134±2mmx30±1mm Cable Cross Section Size 4mm²(IEC),12 AWG No. of cells 144(6x24) Junction Box IP68,3diodes Connector QC 4.10-351/MC4-EVO2A Cable Length (Including Connector) Portrait: 300mm(+)/400mm(-) Landscape: 1400mm(+)/1400mm(-) Front Glass 3.2mm Packaging Configuration 36pcs/Pallet,720pcs/40HQ Container Remark: customized frame color and cable length available upon request

Package&Delivery
Project Case
Cerficication
FAQ 1. Who are we?
We are ANHUI SHANGXIA SOLAR ENERGY CO.,LTD
2. How can we guarantee quality?
We have the most advanced fully automatic production equipment
Always final step by step Inspection system before shipment;
3.What can you buy from us?
Solar Panel, the complete sets for System
4. Are you manufacturer? Or trade company?
Manufacturer
5. What services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW,Express Delivery;
Accepted Payment Currency: USD,EUR,HKD,CNY; etc
Accepted Payment Type: T/T,Cash;
Language Spoken: English,Chinese,French
6. What is the lead time?
Normally 15 working days after advance payment.

---
