GNSS Receiver GPS GLONASS L1 Antenna Adhesive Magnetic Mount

Product Details

Product Description

Product Description
GNSS Receiver GPS GLONASS L1 Antenna Adhesive Magnetic Mount
GPS GNSS Antenna Specifications
I. Electrical Specifications
Frequency range (MHz): GPS 1575.42 / GNSS 1602
Antenna LAN Gain (dBi): 28
Polarization type: RHCP (right-handed circularly polarized)
VSWR: ≤1.8
Input impedance (Ω): 50
DC voltage (V): 2.2-5.0
DC current (mA): 5~15
Input connector type: SMA, SMB, Fakra or customized
II. Mechanical Specifications
Dimensions (mm): 45x38x13mm
Cable length (mm): RG174, 3000mm
Operating temperature(°C): -40～75
Housing color: Black
Waterproof: IP66
Installation method: Magnetic Mount or adhesive mount
RoHS compliant
