The product undergoes a necessary process from small-scale testing to pilot testing, transitioning to industrial production. The relevant data from small-scale testing has been further optimized, simulating industrial production. It has the characteristics of static sealing, high temperature resistance, high pressure resistance, no leakage, safety and environmental protection, smooth operation, compact structure, convenient operation, and long maintenance cycle. The 10L/15/20L/25L is equipped with a pulley lifting device.
| MODEL | GSHA-10L | GSHA-15L | FCHA20-50L | FCHA100-250L | FCHA300-500L |
| CAPACITY | 10L | 15L | 20-50L | 100-250L | 300-500L |
| WORK PRESSURE MPa | -0.1-10.0 | 0.1-10.0 | -0.1-10.0 | -0.1-10.0 | -0.1-10.0 |
| WORK TEMPERATURE C° | -15-320 | -15-320 | -15-320 | -15-320 | -15-320 |
| rpm | 0-750 | 0-750 | 0-400 | 0-400 | k0-400 |
| Motor power KW | 0.37 | 0.37 | 1.5/2.2/3.0 | 3.0/5.0 | 5.0/7.5/11.0 |
| Electric-heating power KW | 6.0 | 8.0 | 9.0 | 10-15.0 | 18-45 |
| Control system | It can be equipped with a high-precision PID control system (automatic or manual control), with a control accuracy of ± 1.5C °, and has functions such as temperature setting, temperature display, speed display, and stepless speed regulation. |
| Main materials | 09MnNiDR/16MnDR (low temperature steel), 15CrMoR (high temperature steel), stainless steel S30408/S32168/S31603, S39042. Titanium material, duplex steel, shackle material, Hastelloy alloy, staggered material, Monel, etc., and explosive composite plates made of these materials. |
| Heating form | Electric heating, jacket thermal oil, jacket steam, outer half pipe, inner coil pipe |
| Mixing form | Turbine self suction, disc turbine, asymmetric turbine, disc inclined blade, four wide blade, propulsion, propeller, anchor, frame, screw belt, etc |
| Application | Catalytic hydrogenation, high-pressure reactions, agrochemical pesticides, hydrothermal synthesis, hydrometallurgy, polymerization condensation, aluminum tin oxide, petrochemicals, fluorination oxidation, deep cooling, etc |
| Shaft sealing form | Magnetic coupling driven static sealing, zero leakage, long service life, simple installation, safe and environmental friendly |
| Remarks | Other special requirements, touch screen intelligent control, program control, and connection to DCS systems shall be designed, manufactured, and configured according to user needs |
