| Name | Measure | |
| Main parameters: | | |
| Bucket capacity | m3 | 0.92 |
| Operating weight | kg | 20800 |
| Engine: | | |
| Model | | Hyundai HE6.7 |
| Engine Type | | Diesel, watercooled, Diesel, watercooled, 4 stroke, 4 cyl. in line, direct injection, turbo charged. |
| Rated output | h.p/kW | 173/129 |
| Rated speed | r/min | 2200 |
| Max. Torque | kgs*m / r/min | 81.6/1400 |
| Engine Capacity | cm3 | 6700 |
| Accumulator battery | | 2*12V*100Ah |
| Dimensions: | | |
| Length | mm | 9680 |
| Width | mm | 2490 |
| High | mm | 3350 |
| Clearance | mm | 345 |
| Wheelbase | mm | 2800 |
| Track width | | 1874 |
| Operating range: | | |
| Длина стрелы | mm | 5650 |
| Длина рукояти | mm | 2000 |
| Maximum Digging Range (A) | mm | 9110 |
| Ground level maximum digging range (A ') | mm | 8870 |
| Maximum Digging Depth (B) | mm | 5480 |
| Maximum vertical digging depth (B ') | mm | 5240 |
| Maximum digging height (C) | mm | 9500 |
| Maximum unloading height (D) | mm | 6670 |
| Minimum rotation radius (E) | mm | 3700 |
| | | |
| Tyres: | | |
| Size | | 10.00-20 16PR |
| Type | | Double |
| Rear blade: | | |
| Width and height | mm | 2490*610 |
| Max. lifting height | mm | 445 |
| Max. Depth of Depth | mm | 120 |
