ATEX Approved Coriolis Mass Flow Meter with Qan, Iecex, Qar, Metrological Certification for Quantitative Loading

Product Description

Coriolis Mass Flow Meter with ATEX , QAN, IECEx-QAR, SEIL, Metrological Certification for Quantitative Loading
Coriolis mass flowmeter can directly measure the mass flow-rate, density and temperature of the flowing medium.
The flowmeter is an intelligent meter with digital signal processing as the core, thus a dozen of parameters can be outputted for user according to the three fundamental quantities above. Featured with flexible configuration, strong function and high cost perfomance, the Coriolis Mass Flowmeter is a new generation of high-precision flow meter. Coriolis Mass Flowmeter is a new generation of high-precision flow meter, which is flexible configuration, powerful function and high cost perfomance.
Advantages of Coriolis mass flow meter
1. Maintenance-free
2. HIgh accuracy & reliability
3. Shows many parameters simultaneously, such as mass flow, temperature & density
4. Compact design with no moving parts, no special mounting and no flow conditioning required.
Andisoon mass flowmeter passed ATEX , QAN, IECEx-QAR, SEIL2, Metrological Certification
It can be used to directly measure the mass flow rate of fluid in pipeline without the influence of temperature, pressure and flow velocity.
High accuracy and excellent repeatability. Wide range ratio (100:1).

Accuracy	0.1% (Optional), 0.15%, 0.2%, 0.5% (Default)
Repeatability	0.05% (Optional), 0.075%, 0.1%, 025%(Default)
Density	±0.001g/cm3
Temp.	±1°C
Answer the liquid material	304 , 316L, ( Customizable: Monel 400, Hastelloy C22 , etc.)
Measuring medium	Gas, Liquid and Multi-phase flow

Product Parameters
- Quantitative loading : the process of loading cargo according to a pre-set quantity or volume. This process typically uses flow meters or other measuring devices to ensure that the amount of cargo loaded precisely meets the specified target. This method is common in the transportation of liquids or bulk materials to ensure that the quantity loaded each time is consistent, avoiding waste or shortages.
- Loading liquids in the petroleum and chemical industries, such as gasoline, diesel, etc. - Loading bulk materials like grain, feed, etc. - Other situations where precise control of the loaded quantity is required. Quantitative loading helps to improve loading efficiency, reduce errors, save costs, and ensure the accuracy and reliability of the logistics process.

Mass flow meters are known for their high accuracy, wide measuring range and reliable performance, and have been successfully used in various industries over the past many years.
Unlike other instruments that are limited to measuring liquids at normal pressure and temperature, ANDISOON excels in measuring under challenging conditions, including high pressure, high viscosity, and high and low temperatures. For example, when measuring CNG (compressed natural gas), the difficulty lies in the high pressure. However, ANDISOON's sensors can withstand high pressures, allowing the necessary increase in flow tube thickness, allowing the transmitter to detect signals with greater sensitivity.
Therefore, ANDISOON's mass flow meters specially designed for CNG gas dispensers have been widely used in the domestic market
In the field of cryogenics, Andisoon has developed a backflow meter and a liquid phase injection meter for LNG refueling stations, with a minimum temperature of -196°C.
In the field of process control, Andisoon has developed a micro-bend type mass flowmeter, with a maximum flow rate of up to 300t/h, widely used in petroleum, chemical and other industrial conditions. Our Advantages
The product has obtained type approval from China Classification Society, ATEX certification, IECEx certification, India PESO certification, and SIL functional safety certification.
1. Customer: What is the delivery date?
Andisoon: Our stock is based on GB/DIN flange, with a delivery date of 10 days. We also accommodate other flanges like ANSI/JIS or thread connection, with a delivery date of 15 days.
2. Customer: Can you design according to my requirements?
Andisoon: Yes, we offer OEM service and can tailor products to your specifications.
3. Customer: What is the warranty period?
Andisoon: The quality guarantee period is 12 months from the completion of installation and commissioning by the purchaser, or 14 months from the date of delivery (whichever comes first), excluding maintenance kits or small accessories.
