| US$200.00 | 1 Piece (MOQ) |
| Specification: | 3T-180T, 6m-60m, 0.55KW-75KW |
| Material: | SS304 SS316L (The pump body, pump cover and impeller) |
| Impeller: | 1.Open type impeller, there is no blind corner;2Close type impeller;3.Semi-open type impeller |
| Operate condition: | Sanitary centrifugal pump is close to HORIZONTAL transport of high and low level, is not the Self-priming type. |
| Surface treatment: | The part contact with mdedium is Polished, And other part is Sand Blasted |
| Max inlet pressure | 0.5MPa |
| Temperature range: | -10 to Degree +140 Degree |
| Flushable mechanical sealing: | Water pressure: __Max 0.1MPa Water lift: ___0.25-0.5L/min |
| Standards: | DIN \ SMS |
| 1. Configuration of "ABB" brand three-phase AC motor is in accordance with the International Electrotechnical CommissionIEC60034. IEC60072 standard design comply with European "CE" Marking requirements |
| 2. The Explosion-Proof motor also available, that can meet with the requirement of different Applications. |
| 3. It has excellent electric performance, low niose and low vibration. The protection grade is IP55, insulation grade is F. |
| 4. Operate involtage: 3Kw, 220-240V/380-420V 3Kw, 380-420V/660-690V |
| 5. Requency: ____50Hz/60Hz |
| 6. Working method: ____Continuous(SI) |
