Vertical Bolted Splice Cement Silo for 200t/300t/500t/600t/800t/1000t

Product Description

Product Description

Vertical Cement Silos for Space-Saving Solutions
Supported by four round pipe legs, the bottom of the silo ensures stability and durability. The top of the silo is equipped with a dust collector and pressure safety valve, ensuring a clean and safe environment.
These cement silos are ideal for use as a supporting product for concrete mixing plants or buildings. They are designed to be rainproof and moisture-proof, making them suitable for various weather conditions. The specifications and dimensions of the silos can be customized according to the specific requirements of customers.
The cylindrical support structure of the silo includes dust removal equipment at the top to prevent dust leakage. Additionally, an arch breaking device is installed at the bottom to prevent powder agglomeration and ensure smooth powder discharge. The silo is also equipped with material level sensing equipment, allowing users to monitor the material usage in the warehouse at any time.

Volume	Diameter	Silo body height	Layers of silo body	Pieces each layer	Weight
50t	3160 mm	4260 mm	3	4	4.5 T
100t	3160 mm	8700 mm	6	4	6 T
150t	3160 mm	13000 mm	9	4	9 T
200t	4000 mm	11360 mm	8	5	12 T
200t	4500 mm	8700 mm	6	6	12 T
300t	5300 mm	8700 mm	6	8	17 T
500t	6800 mm	7300 mm	8	8	21 T
600t	6800 mm	8700 mm	6	8	28 T
800t	8000 mm	10100 mm	7	10	43 T
1000t	8000 mm	13200 mm	9	10	56 T

Detailed Photos
Site installation:
Packaging & Shipping

---
