| US$10,000.00-30,000.00 | 1 Piece (MOQ) |
| Suitable material | LDPE, PE.HDPE, so on | ||
| 1L | |||
| Output capacity | 350-500 pcs/h | ||
| Size | 4.2X2.2×2.6(M) | ||
| Weight | 5TSuitable materialMax volume | ||
| System | Specification | Parameters | Note |
| Plasticizing system | Summarize | High efficient low power consumption plasticization system, transducer control,self-protect function when started at low temperature | |
| Reducer | Hard finishing, High intension, Low noise reducer | ||
| Screw | ∮55 mm,L/D ratio 24, 38CrMoALA | Cooling system available | |
| Plasticization | 75 Kg/H | HDPE | |
| Heating Zone | 3 Aluminum Heater | Automatic heating | |
| Heating power | 5 KW/H | ||
| Extrusion Motor | Three-phase asynchronous motor | ||
| Cooling Fan | 3 zone | Automatic cooling | |
| Extrusion system | Summarize | High-grade alloy steel, center feeding | |
| Die head number | 1 | ||
| Center distance of die heads | / | ||
| Max die mouth | ∮170mm | ||
| Heating zone | 3 Stainless steel heating cycle | ||
| Heating power | 5~7KW | ||
| Clamping system | Summarize | High intension, rigidity, center mold locking, stable mold opening, and clamping system | |
| Clamping force | 65KN | ||
| Template distance | 420X350mm | ||
| Max mold size | 400X350mm | ||
| Electric system | Summarize | PLC+ touch screen(man-machine interface)standard extrusion blow molding machine controlling system(AUTO monitoring, fault-alarm, auto counting, auxiliary function available) | TAIWAN WISETECH system |
| Operate interface | Touch screen, automatic self-diagnose alarm system | ||
| Temperature control | The automatic temperature control module | ||
| Movement control | TAIWAN WSIETECH, Chinese/English Version | ||
| Electric protection | Ampere overload, electric short circuit self-protection function | ||
| Hydraulic system | Summarize | Multiple function hydraulic integrated block Proportional control, high efficient | |
| Servo system | Three-phase asynchronous servo motor (380V/220V,50/60HZ) | ||
| Servo pump | Japan Sumitomo | ||
| Valves | Imported oil pump valves and connections | ||
| Oil pipes | Double layer overpressure resistant | ||
| System pressure | 60Kg/cm² | ||
| Cooling system | Separate water cooling cycle, oil cooler cooling system | ||
| Pneumatic system | Summarize | Taiwan AIRTAC pneumatic system | |
| Air pressure | 0.6 Mpa | ||
| Air displacement | 0.7M3/min | ||
| Electromagnetic valve | Taiwan AIRTAC | ||
| Cooling system | Summarize | The separate cooling system of mold, barrel, and oil system | |
| Cooling medium | Water | ||
| Water flow | 65L/min | ||
| Water pressure | 0.3-0.6MPa | ||
| electronic parts | |
| Name | Trader |
| Micro computer control system | TAIWAN WISETECH |
| Temperature Controller | TAIWAN HUIBANG |
| Auxiliary Relay | OMRON |
| contactor | SOLID |
| Electric motor | Three phase 220V or 380V |
| Power Source | TAIWAN MEANWELL |
| Transducer | ABB from SWIZERLAND |
| hydraulic parts | |
| Name | Trader |
| Oil pump | TAIWAN HIGH-TECH |
| Valve | YUKEN |
| Oil pump and connection | YUKEN |
| Sealed part | HALLITE |
| air control system | |
| Name | Trader |
| Cylinder | AIRTAC |
| Air Valve | AIRTAC |
