US$26,200.00-30,250.00
|
1 Set
(MOQ)
|
Basic Info.
Model NO.
HD-70P Circular saw machine
Process Usage
Metal-Cutting CNC Machine Tools
Movement Method
Linear Control
Control Method
Semi-Closed Loop Control
Performance Classification
High-End CNC Machine Tools
Certification
ISO9001:2015, ISO14001:2015
Model No
P Series Circular Saw Machine
Feed System
AC Servo Motor + Ball Screw
Circular Saw Blade Dimensions
285 X 32 X T2.0/ T1.75
Automatic Feed Loader
6 Meters
Cutting Material
Copper, Stainless Steel,Mild Steel,Aluminum
Features
High Speed,High Precision Cutting,Durable Quality
Shipment Way
Shipment by Vessel / Railway
Delivery Time
About 20-25days
Transport Package
Standard / Wooden Box Packaging
Specification
L 7180 * W 2050 * H 1790
Production Capacity
300sets/Mothly
Product Description
Detailed Photos
Product Description
About CNC Automatic High-Speed Circular Saw Machine:1. Man-Machine Interface System
The easy-to-operate intelligent automated servo system with user-friendly touch screen and PLC control system ensures the efficiency and reliability of program operation.2. One-Piece Machine Foundation
The machine foundation uses high strength casting ensures stable machine performance, high cutting efficiency,and precision. Foundation is equipped with a circulating water cooling tank, which can satisfy the needs of using water-based coolant fluid when cutting tough alloy steel materials.3. New Gearbox Structure
The innovative designed gearbox structure and configuration apply to a wide range of cutting materials.4. Remnant Management Device (Third vise)
The unique short remnant clamping structure(P series)changed from a single cylinder to double cylinder separate actions with a vertical clamping device, increase the devise stability and reliability, blade lifetime, yield rate, and saves costs.5. Innovative Automatic Feeding Device
The material feed utilizes a servo-controlled motor with ball screw and linear guiding. Specially designed structure of feed clamp yaw effectively increases the precision and reliability.6. Spray-Mist Lubricant Cooling System
The advanced MQL circular saw blade spray-mist lubricant technology can increase blade service life.
Standard |
Optional |
| 1 | One set of two-axis electrical system | 1 | Oil mist collector |
| 2 | Hydraulic system | 2 | Extended feed loader |
| 3 | Automatic spray-mist lubrication system | 3 | Power-driven wire brush |
| 4 | Automatic material feed loader | 4 | Cooling water pump |
| 5 | Spiral type chip conveyor | 5 | Automatic chain type chip conveyor |
| 6 | Wire brush | 6 | Third Vise |
| 7 | One air spray gun | 7 | Extended carrying device for cut-off workpiece |
| 8 | Circular saw blade | | |
| 9 | One set of tool kits | | |
Product Parameters
| P SERIES CIRCULAR SAW MACHINE TECHNICAL DATA |
| Specifications | HD-70P 2-Axis |
CUTTING
CAPACITY | Round bar (mm) | 10-70 |
| Square bar (mm) | 10-60 |
| Trimming length (mm) | 10-100 |
| Single feed length (mm) | 5-800 |
| Remnant length (mm) | 70 |
| Perpendicularity Tolerance (mm) | ±0.05/100 |
| SAW BLADE | Dimensions (mm) | Φ285 x Φ32 x T2.0/t1.75 |
| Pin hole (mm) | Φ63/4/Φ11 |
| Number of teeth (Z) | 54, 60, 72, 80, 100, 120 |
| PARAMETERS | Working voltage (V) | 380 |
| Total power (KW) | 14.5 |
| Machine weight estimated (Loader included) (KG) | 4500 |
| Machine dimensions estimated (mm) | L 2700 x W 2050 x H 1790 |
| Machine dimensions estimated (loader included) (mm) | L 7180 x W 2050 x H 1790 |
| LOADER | Number of pieces (P) | Φ70 x 6 m x 10 |
| Length (m) | 3-6 m |
| * Please note: all product technical information, parameters, specifications, dimensions, and designs shown in this catalog are subject to change without prior notice. For more information, please contact Hengerda. |
|
