OEM ODM Outdoor Indoor Fullcolor SMD P10 P8 P6 P4.81 P3.91 P3 P2.5 P2 P1 Rental Curved Digital Advertising Video Wall LED Sign Billboard Panel Screens Display

Product Description

Specification

Model	VI/HI1.9	VI/HI2.5	VI/HI2.6	VI/HI2.9	VI/HI3.9	VI/HI4.8
Pixel Pitch(mm)	1.95	2.5	2.6	2.97	3.91	4.81
Pixel Matrix Per Sq.m	262144	160000	147456	112896	65536	43264
Pixel Configuration	SMD1515	SMD1515	SMD1515	SMD2121	SMD2121	SMD2121
Scan	1/32	1/25	1/32	1/28	1/16	1/13
Brightness (cd/m2)	≥1000
Module Dimension	250×250mm
Cabinet Dimension	V -- 500x500mm/H -- 500x1000mm
Cabinet Material	Die Casting Aluminum
Cabinet Weight	V -- 8KG/H -- 14KG
Power Con.(W/m2) (Max / Avg)	800W/200-300W
Service Access	Front/Rear
Refresh Rate (HZ)	≥3840
Grey Scale (bit)	≥16
Viewing Angle (H/V)	160°/160°
IP Rate	IP43
Input Voltage (AC)	110V / 240V

Model	VI/HI2.6	VI/HI2.9	VI/HI3.9	VI/HI4.8
Pixel Pitch(mm)	2.6	2.97	3.91	4.81
Pixel Matrix Per Sq.m	147456	112896	65536	43264
Pixel Configuration	SMD1415	SMD1415	SMD1921	SMD1921
Scan	1/32	1/21	1/16	1/13
Brightness (cd/m2)	4000
Module Dimension	250×250mm
Cabinet Dimension	V -- 500x500mm/H -- 500x1000mm
Cabinet Material	Die Casting Aluminum
Cabinet Weight	V -- 8KG/H -- 14KG
Power Con.(W/m2) (Max / Avg)	800W/200-300W
Service Access	Front/Rear
Refresh Rate (HZ)	≥3840
Grey Scale (bit)	≥16
Viewing Angle (H/V)	160°/160°
IP Rate	IP65
Input Voltage (AC)	110V / 240V

Company Profile LEDFUL is a top LED display manufacturer with 13 years rich experience providing 3 years warranty.
We concentrate on LED Poster, Transparent LED screen, Outdoor & Indoor commercial LED billboard,
Rental LED screen, Sports LED display.
Certifications Due to our best balance of quality & price with strong reputation, our LED displays are exported to 83
countries in Europe, America, Asia, Africa, and Oceania with successful 5600 projects. Besides LEDFUL
obtained CE, FCC, RoHS, CCC, UL, ETL, EMC, ISO9001 certificates. A state-of-the-art manufacturing
and testing facility ensures LEDFUL products of the high and stable quality.
Each product goes there 16 monetary procedures 23 operating procedures in 1500 tests and experiments.
Packaging & Shipping All employees are honest, responsible and diligent. Dedicated to professional,
high efficient and caring features, our experienced sales engineers listen to you,
think more for you.
In addition, take good care of each detail of your order, packages and shipping.
We also welcome deep customized, OEM, ODM orders and distributors application.
LEDFUL is a trusted one-stop LED display solution provider with more designs and more solutions.
Our partners are media advertising, audio, video & light, retail, property, religion, sports, event, studio.
Front service, double sided, column, flex, curved, sphere, 90 degrees, any irregular shaped LED display
are available.
Our corporate philosophy is to maximize the value for our customers and to provide the best service for
our customers. FAQ
1.Q:how about the power consumption? A: Each cabinet has 3 sets 300W power, that is 900W. The max power consumption is 80%, that is 720W per cabinet. The average consumption is 20%, that is 180W. And If we choose LEDFUL energy saving solution, we can save 40% power consumption. 2.Q:Do you provide the structure with the screen together?
A: We suggest to customize the structure in your local market, because it is big and heavy, it will cost too much for shipping. We shall provide the structure CAD Drawing, so that you can customize it easily. 3.Q:How to control it?
A:Wifi, 4G, cloud, USB, remote control.
4.Q: Are you trading company or manufacturer?
A: LEDFUL is a professional LED display manufacturer, having been enrolled in led display industry with professional
R&D team and skilled QC team for 13 years.
5.Q: What is the control system? How is it?
A: We use Nova Taurus Series asynchronous control system. Support cluster play and management.
Support APP/Phone/WIFI Ipad/Laptop/PC/Cloud control. It's very easy and convenient to control.
6.Q: What is your best service?
A: One to one sales engineer to customer responsibility system. We will do:
1) Know your project and provide the best solution for it.
2) Track your order and let you know each step and detail of it.
3) Teach you how to install and use the screen.
4) Care the subsequent use of your screen and ensure vour after -sales service be well.
7.Q: How about your Warranty Term?
A: 3-year warranty. we have professional after-sale team to solve your any questions after you placed an order.
And your exclu-sive sales engineer will also help you to get over any problems. LEDFUL, Makes The World More Colorful.

---
