Professional Vertical CNC Milling Heavy Duty Gantry Metal-Cutting Machine Tools

Product Description

1. Experience precision like never before with the China CNC Large Horizontal Machining Center GMC321 GF-2214. Designed for unparalleled excellence, this state-of-the-art machine redefines accuracy and reliability. Elevate your production processes to new heights of efficiency and streamlining, ensuring premium results every time.
Product Description
1.1 DESCRIPTION The Professional Gantry Vertical CNC Double Column Metal-Cutting Machining Center, meticulously crafted by NANJING NEWSIV EQUIPMENT CO., LTD., exemplifies pinnacle engineering and state-of-the-art technology. This sophisticated machining center is designed to cater to the most demanding industrial applications, providing unparalleled precision, reliability, and operational efficiency. Its robust structure and advanced CNC capabilities ensure every cut is executed with extraordinary accuracy, making it an indispensable asset for high-performance metalworking operations.
FEATURE
1.2 FEATURE
Outstanding Performance, Unwavering Precision, and Superior Rigidity
Our Professional Vertical CNC Milling Heavy Duty Gantry Metal-Cutting Machine Tools are crafted using premium-grade resin sand casting. Featuring a robust box-shaped structural design, this machine excels in both durability and sturdiness.
The machine undergoes an aging treatment that effectively eliminates internal stress, guaranteeing long-lasting stability for consistent, high-quality operation.
Built with exceptional rigidity and strength, this state-of-the-art machine is renowned for its remarkable cutting resistance and high precision, ensuring flawless performance.
Automatic Tool Change System
Experience the unmatched speed and safety of our arm-type tool change system. It delivers swift, seamless, and dependable tool exchanges, enhancing overall efficiency.
Controlled by advanced PLC software, the tool exchange process completes in approximately 8 seconds, significantly reducing non-cutting time and boosting productivity.
Rotatable Control Box
The rotatable, seat-type control panel, along with a portable handwheel operation box, offers unparalleled convenience for operators. This setup ensures easy access and usability from any position.
Equipped with a foot switch, operators can easily clamp and release tools on the spindle head, enhancing operational efficiency and user comfort.
Servo Motor
Our servo motor directly drives the screw rod via coupling, which reduces vibration and enhances precision across all three axes, ensuring smooth and accurate movements.
Featuring a servo motor with a built-in absolute encoder for indirect displacement measurement, this machine forms a semi-closed loop system to guarantee pinpoint positioning accuracy. The three-axis positioning is managed by a sophisticated numerical control system.
1.2 PARAMETERS

Specification		GF-2214/2514/3014/4014	GF-2217/2717/3017/4217	GF-2718/3218/4218	GF-2722/3022/42222/5222/6222	GF3025/4025/5025/6025
X-axis travel	mm	2200/2500/3000/4200	2200/2700/3000/4200	2700/3200/4200	2700/3000/4200/5200/6200	3200/4200/5200/6400
Y-axis travel	mm	1450	1700	2000	2400	2800
Z-axis travel	mm	850	850	1000	1000	1100
Gantry width	mm	1400	1700	1800	2200	2500
X/Y/Z guide track	-	XY:Linear guide track Z:Slide guide track	XY:Linear guide track Z:Slide guide track	XY:Linear guide track Z:Slide guide track	XY:Linear guide track Z:Slide guide track	XY:Linear guide track Z:Slide guide track
Worktable size	mm	2200/2500/3000/4000x1200	2200/2700/3000/4200X1500	2600/3000/4000X1800	2500/3000/4200/5000/6000X2000	3200/4200/5000/6200X2300
Table form (,No.*screw hole)	mm	7-22*150	7-22*220	9-22*180	9-22*203	9-22*226
Spindle type	BT	BT50	BT50	BT50	BT50	BT50
Spindle speed	rpm	6000	6000	6000	6000	6000
Spindle dia	Ø	190	190	190	190	190
Spindle motor	kw	15/18.5	15/18.5	15/18.5	22/26	22/26
X/Y/Z quickly move speed	m/min	15/15/12	15/15/12	15/15/12	12/12/12	12/12/12
Max cutting feed speed	-	1-10000	1-10000	1-10000	1-10000	1-10000
Tool magazine capacity	pcs	24	24	24	24	24
Max tool weight	Kg	18	18	18	18	18
X/Y/Z axis position accuracy	mm	0.008	0.008	0.008	0.008	0.008
X/Y/Z axis repeat position accuracy	mm	0.005	0.005	0.005	0.005	0.005
Max.loading of worktable	g	4000/5000/6000/8000	5000/5000/6000/8000	6000/8000/10000	7000/9000/11000/13000/16000	8000/12000/16000/19000
Distance from the spindle front end to worktable center	mm	270-1120	165-1025	150-1150	150-1150	200-1300
Machine size (L×W×H)	m	6.4/7.4/8.4/10x4x3.7	6.6/7.6/8.6/10.6X4.5X3.5	7.5/8.5/10.5X4.7X3.8	7.5/8.5/10.5/12.5/14.5X5X3.8	8.5/10.5/12.5/14.5X5.7X4.5
Machine weight	t	16/19/22/25	18/21/24/27	23/26/31	24/27/30/35/40	32/37/42/47

Specification		GF3228/4228/5028/6228	GF-3232/4232/5232/6232	GF4037/5037/6037/8037	GF4042/5042/6042/8042
X-axis travel	mm	3200/4200/5000/6200	3200/4200/5000/6000	4200/5200/6200/8200	4200/5200/6200/8200
Y-axis travel	mm	3200	3300	4000	4500
Z-axis travel	mm	1100	1250	1250	1250
Gantry width	mm	2800	3200	3700	4200
X/Y/Z guide track	-	XY:Linear guide track Z:Slide guide track	XY:Linear guide track Z:Slide guide track	XY:Linear guide track Z:Slide guide track	XY:Linear guide track Z:Slide guide track
Worktable size	mm	3200/4200/5000/6200X2300	3200/4200/5000/6000X2700	4000/5000/6000/8000x3000	4000x5000x6000x8000x3000
Table form (,No.*screw hole)	mm	9-22*226	13-22*180	13-28*200	13-28*200
Spindle type	BT	BT50	BT50	BT50	BT50
Spindle speed	rpm	6000	6000	6000	6000
Spindle dia	Ø	190	190	200	200
Spindle motor	kw	22/26	22/26	22/26	22/26
X/Y/Z quickly move speed	m/min	12/12/12	12/12/12	15/15/12	12/12/12
Max cutting feed speed	-	1-10000	1-10000	1-10000	1-10000
Tool magazine capacity	pcs	24	24	24	24
Max tool weight	Kg	18	18	18	18
X/Y/Z axis position accuracy	mm	0.008	0.008	0.008	0.008
X/Y/Z axis repeat position accuracy	mm	0.005	0.005	0.005	0.005
Max.loading of worktable	g	9000/12000/15000/18000	16000/20000/23000/26000	16000/20000/26000/30000	16000/20000/26000/30000
Distance from the spindle front end to worktable center	mm	200-1300	175-1425	250-1500	250-1500
Machine size (L×W×H)	m	8/10/12/14X6X4.8	9/11/13/15X6.5X4.8	11/13/15/19X7X5	11/13/15/19X7.5X5.2
Machine weight	t	35/40/45/50	40/45/50/60	50/57/65/80	55/63/73/93

1.4 STANDARD ACCESSORIES

1	24 tool magazines	6	Tri-color warning light	11	Spindle cooling	16	Portable chip blowing air gun
2	Workpiece Cooling System	7	Machine cleaning water gun	12	Fully enclosed protective cover	17	Large flow chip flushing device
3	Automatic lubrication system	8	Spindle output water	13	Foundation screws and pads	18	Spindle nose labyrinth dust blower
4	Spindle air curtain dustproof system	9	Electric cabinet heat exchanger	14	Tools and Toolboxes	19	Chip trolley
5	LED working light	10	Network transmission and CF card function	15	Double screw conveyor& chain chip conveyor	20	Transformer

2. SERVICE
2.1TRAINING AND INSTALLATION
2.2AFTER SALES
1. Starting from the BL date, the manufacturer offers a one-year comprehensive 'three guarantees' service for the product (user-induced damage will incur additional costs).
2.
In the event of a machine tool malfunction, the manufacturer will accurately diagnose the issue and provide immediate assistance upon receiving user feedback. If the cause is indeterminate,a response will be provided within 24 hours.
2.3 Package
FACTORY WORKSHOP
3.Discover the Advanced Capabilities of our FACTORY WORKSHOP: NANJING NEWSIV EQUIPMENT CO., LTD. proudly presents our state-of-the-art workspace, meticulously designed to house our Professional Vertical CNC Milling Heavy Duty Gantry Metal-Cutting Machine Tools. Witness a seamless blend of innovation and precision as we push the boundaries of metal-cutting technology.
Company Profile
4. Company Strength
4.1 General Situation
Founded in 1993, Anhui Gaochuan Sikai CNC Equipment Manufacturing Co., Ltd. (formerly Nanjing Sikai), now proudly operating as NanJing Newsiv Equipment Co., Ltd., made a strategic transition to Ma'anshan, Anhui in 2021, demonstrating our commitment to growth and innovation.
As a high-tech enterprise, we specialize in the innovative design and manufacturing of CNC machine tools. Our flagship products, boasting completely independent intellectual property rights, have been recognized with the prestigious Jiangsu Province High-tech Product Certificates, underscoring our dedication to technological excellence.
Recognized for our high-tech prowess, we forged a strategic alliance with China Transmission Group in 2010. With their robust support, we continuously strive for excellence and innovation. Through collaborations with illustrious international and Taiwanese machine tool companies, we ensure superior quality and performance, aspiring to meet and exceed global standards.
4.2 Participation in Exhibitions
Certifications
4.3 Certifications: Our unwavering dedication to excellence is exemplified by an array of prestigious certifications. These accolades affirm that our Professional Gantry Vertical CNC Double Column Metal-Cutting Machining Center consistently adheres to the pinnacle of quality and safety standards.
4.4 FAQ: Immerse yourself in our detailed FAQ section, where we comprehensively address all your pressing inquiries about our advanced machining center. From intricate technical specifications to operational guidelines, we provide all the essential information for making a well-informed decision.
5. Other Products: Delve into our broad spectrum of revolutionary equipment beyond the Professional Gantry Vertical CNC Double Column Metal-Cutting Machining Center. Uncover avant-garde solutions meticulously crafted to fulfill diverse industrial demands with unrivaled precision and superior performance.

---
