| Name | Prepainted Galvanized Steel Sheet |
| Type of substrate | Hot dip galvanized, Galvalume, Electro galvanized, Cold rolled steel, Aluminium |
| Thickness | 0.1mm~3.0mm |
| Tolerance | Thickness: ±0.01mm |
| Width | 600-1250mm ( Normal:1250, 1200,1000, 914, 900, 762, 750mm) |
| Top Paint | 15-35 micron(Normal:10-20mic) |
| Back paint | 7-35 micron(Normal:5-7mic) |
| Coil weight | 3-5 tons or as your requirement. |
| ID | 508/610 mm |
| Grade | SGCC/DX51D+Z, DX52D+Z, SGCD/DX53D+Z,SGCE/DX54D+Z, SGCH |
| Coating type | Top paint: PE, SMP, HDP, PVDF, PU |
| Functions: Decorative, Machinability, Weather resistance, Scrath resistance, Stain resistance, Chemical resistance, Adhesion resistance | |
| Primer paint: Polyurethane, Epoxy, PE | |
| Functions:Machinability,Corrosive resistance,Adhesion, Scrath resistance | |
| Back paint: Epoxy, Modified polyester | |
| Functions: Scrath resistance, Bending adhesion, Corrosive resistance | |
| Packing | Standard export package .Plastic film in the first layer,second layer is Kraft paper. Third layer is galvanized sheet. |
| Application | Building industry, structural use, roofing, commercial use, household appliance, industry facilities, office buildings |
