Horizontal Torno Mecanico Universal Ck6250b Lathes Manual Gap Bed High Speed Metal Parallel Precision Bench Lathe

Product Description

Product Description
The YUCY-6150 is a manual cnc lathe which has high rigidity and stability. The structural stiffness and transmission stiffness of the lathe are very excellent, not only the precision is stable, but also can perform heaving cutting. This series machine is suitable for turning internal and external cylindrical surface, conical surface and other rotating parts. It can process all kinds of common metric, inch, modulus and diameter pitch threads, and broach oil grooves and keyways. This series of lathes is easy to operate, which can reduce the learning cost of workers and provide work efficiency. The lubrication system of the machine is out of the box circulation, which improves the machining accuracy.

Main Features
Excellent rigidity Excellent stability Maximum swing over bed: 500mm Maximum swing carriage: 300mm Speed range of spindle: 9-1600RPM Spindle tape: MT6 Spindle hole: 52mm Detailed Photos
Product Parameters

Speciflcations	CK6150	CK6250	CK6150B	CK6250B	CK6150C	CK6250C
Swing over bed	500mm(20")
Swing over gap		710mm(28")		710mm(28")		710mm(28^^ )
Efective width gap		240mm(10")		240mm(10^^ )		240mm(10° )
Swing over ca rriage	300mm(12° )
Maximum length of workpiece	750,WOO,1500,2000,3000,4000, 5000 mm(29°,40°,60",118",157" . 196")Note: The lathe with saddle has no specification of 4000,5000mm
Range of spindle speeds	24(steps)9-1600 r.p.m		24(steps)9-1600 r.p.m		12(steps)16-1200 r.p.m
Spindle tape	MT6		90(1:20)		120(1:20)
Spindle hole	52mm		82mm		105mm
Spindle nose	C-6		D-8		D-11
Longitudinal feeds	93 0.028-6.43mm/rev		93 0.028-6.43mm/rev		65 0.063-2.52mm/rev
Cross feeds	93 0.012-2.73mm/rev		93 0.012-2.73mm/rev		65 0.027-1,07mm/rev
Lead screw pilch	12mm
Metric thread range	48 0.5-224mm		48 0.5-224mm		22 1-14mm
Inch thread range	48 72-1/8 t.p.i		48 72-1/8 t.p.i		17 2-28 t.p.i
Module thread range	42 0.5-112mm		42 0.5-112mm		18 0.5-7mm
Diametral pilch thread range	45 56-1/4Dp		45 56-1/4Dp		24 56-4Dp
Dia of tailstock quill	75mm
Morse taper of tailstock quill	No.5
Max travel of tailstock quill	150mm(6")
Main molorpower	7.5Kw
Machine overall dimensions	750=2375 x1043x1325(mm) 1000=2625x1043x1325(mm) 1500=3125x1043x1325(mm)
	2000=3625x1043x1325(mm) 3000=4625x1043x1325(mm)
Net weight	750mm=1950Kg 1000mm=2100Kg 1500mm=2300Kg 2000mm=2500Kg 3000mm=2700Kg

Company Profile
Lizhun Machinery Co., Ltd. is a company focused on innovation, development and production of CNC machining centers and CNC lathes. Adhering to the spirit of innovation and excellence, the company has provided many famous enterprises at home and abroad with extremely superior machines in performance, precision and quality. In the future, Lizhun will continue to maintain the spirit of innovation and excellence to provide strong and lasting support for the processing industry, and provide excellent processing machines for 5G, aviation, automobile and other industries.
Lizhun Machinery Co., Ltd. is located in Dongguan, Guangdong province. The product exhibition hall is located in Songshan Lake, Dongguan City, with beautiful scenery and elegant working environment. The factory is located in Dalingshan, with complete facilities and experienced staff. The staff has many years of experience in innovation, development, assembly and production, which ensures that each machine has extremely outstanding quality and performance when it leaves the factory.
The factory covers a large area and has multiple production lines to ensure production capacity and supply capacity. Excellent capacity and supply capacity can ensure that customers can receive the machine within the agreed time which can avoid a series of problems caused by insufficient capacity.

FAQ
1. Is it all right to make customer's own brand name?
A: yes. we are available with OEM

2. Are you a manufactuer or trading company?
A:We are the manufacturer

3. Can you do the design for us?
A: yes. if you want a different control system design or higher column , we are available.

4 . What is your terms of delivery?
A: FOB shenzhen.

5. What's your payment term?
A: T/T OR L/C at sight.

---
