US$200.00-60,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Frequency Characteristics
High Frequency
Power Source
Linear Regulated Power Supply
Application Range
Industry, Bank, Data Center, Hospital, etc
Dielectric Strength
2000V No Breakdown Within One Minute
Insulation Class
Class F, Temperature Resistance 155ºC
Input Voltage
Three-Phase 304~456V
Output Voltage
380V±1-5% / Can Be Set
Transport Package
Wooden Box
Specification
to different type
Production Capacity
5000set/Year
Product Description
Product Description
| Pattern | SBW | DBW |
| Phase | 3Ph | 1Ph |
| Specification | 10KVA~3000KVA | 3KVA~500KVA |
| Input Voltage | 304V~456V | 176V~264V |
| Output Voltage | 380V±1-5% / can be set | 220V±1-5% / can be set |
| Stabilization Time | 1-5% / be able to adjust |
| Voltage Accuracy | Setting time is less than 1.5s when the input voltage compares with the rated voltage changes within 10%. |
| Ambient Temperature | -10ºC~+45ºC, the highest monthly average temperature should not exceed 35ºC. |
| Working status | Fully automatic,long-term operation, arbitrary switching of mains/stabilizing voltage. |
| Display Method | The current and voltage adopt LCD large screen display, man-machine dialogue interface, and abnormal status indicator display. |
Stabilizer Protection
| Over and under voltage protection | When the input voltage exceeds the voltage regulator's over-voltage or under-voltage value, the equipment will automatically protect the no-voltage output. |
| Over current protection | When the current exceeds the rated value, the input is automatically cut off. |
| Overload, short circuit protection | When the load exceeds the specified overload capacity or short circuit of the equipment, the power supply can be automatically cut off within the specified time. |
| Limit protection | When the brush operation exceeds the area, the adjustment is automatically terminated. |
| Mains bypass function | When the voltage stabilizer needs maintenance or malfunctions, the manual switch can be switched to supply power in a direct connection state. |
| True effective sampling circuit control | High accuracy, good sensitivity, good measurement rate and frequency characteristics, high input impedance, low output impedance, wide power supply range and low power consumption. |
| Back to middle function | When the sampling voltage is lower than the lower limit reference voltage or higher than the upper limit reference voltage, the brush will automatically return to the center. |
Product Application
Company Profile
Shanghai Wenfeng Electric Co., Ltd. is a large-scale production base of voltage stabilizer products in China and a leading brand in the domestic voltage stabilizer industry. Since its establishment in 1995, the company has successively established offices in Beijing, Guangzhou, Shenyang, Chengdu, Qingdao, and Xi'an. The newly completed international standard factory building in 2010 covers an area of 12,000 square meters and has more than 150 employees, of which 30% are electric engineering and technical personnel, and the coverage rate of bachelor degree or above is more than 25%. Wenfeng Enterprise has a high level of industry representativeness in power supply technology research and development system design, manufacturing technology, product quality, etc.
