Lifting Magnet for Handling Material in Steel Mill

Product Description

Lifting Electromagnet
Lifting Electromagnet is special electromagnet used for lifting attached materials. The equipment utilizes the electric & magnetic physical quantity to lift magnet- conductive materials, which is indispensable for lifting and
transporting magnet-conductive materials such as steels in metallurgy industry, mine industry, machinery industry, shipbuilding industry and transportation industry, etc.
Main Features
1. Adopt totally sealing structure with good property of moisture-proofing. Non-magnetic fender adopts rolling manganese plate with good property of weldablity, magnetism-isolation, wear-resistant and shockproof.
2. Introduce the technology from abroad through improvement and innovation, as well as optimum design by computer with reasonable structure, light dead-weight, strong attraction force and low energy consumption.
3. The energizing coils are processed by special technology to improve the electrical and mechanical property. Heat-resistant grade of insulating material reaches grade C with a long service life.
4. Rated duty cycle of normal electromagnet is increased from 50% in the past to 60%, which improves the efficiency of the electromagnet.
5. High temperature electromagnet adopts unique method of heat-protection and radius-protection, the temperature of the attached materials is increased from 600ºC in the past to 700ºC, which expands application range of the electromagnet.
6. Complete equipment provided with auxiliary units such as Control Cabinet, Cable Reel, etc.
7. Simple and convenient to install, operate and maintain.
Guide for Model Selection
1,What's the attached material? Choose the suitable series according to the attached material.
2,The specification of material attracted? such as weight,length,width or number.
3,The specification of hoist, such as: tonnage, height and brake type of hook.
4,The application environment, such as temperature of material attached, indoor or outdoor.
5,The cycle duty: when exceed 60%, choose high frequency type.
6, Selection of corollary equipment: cable reel and control cabinet.

Series of electromagnet	Examples of attached materials	Remark
5	cast iron ingot,steel ball, various steel scrap,iron powder	balk cargo or baling scrap
61	various steel scrap	made to order for small box-shaped container
19-72	special for coiled bar(high speed wire)	contacted with two points of the wire rod, light, large attraction
12	binding screw-thread steel,small round steel,profiled steel	double coils structure, farther permeability depth
39	binding reinforced bar steel,small round steel,profiled steel	standardized, systemized ,farther permeability depth
22	billet, bloom, steel ingot, profiled steel, etc	standardized, systemized
32	billet, bloom, steel ingot, profiled steel, etc	standardized, systemized
42		standardized, systemized
92	billet, bloom, steel ingot, profiled steel, etc	active magnetic pole structure
25	steel tube, round bar, etc	standardized, systemized
35	steel tube, round bar, etc	standardized, systemized
85	huge diameter steel tube	standardized, systemized
17	profiled steel, rail, beam blank, etc	standardized, systemized
27	profiled steel, heavy rail, beam blank, etc	light deadweight, super-long heavy rail by combined units
37	profiled steel, heavy track, profiled billet, etc	special for round materials
03	large steel ingot, casting plate blank, thick steel plate	special for lifting and transporting thick materials
84	speical for wide and heavy plate,and medium-thick plate	including super thin steel plate (δ≤4mm) ; series of large type can lift more plates
04	single sheet steel	suitable for electromagnetic clamp on the machine and cutting position
16,26,36	special for steel band roll	no damage to coil during lifting, the most ideal lifting tool with two patents

Application Schematic
