Honle 2000va SVC High Accuracy Full Automatic AC Voltage Stabilizer Regulator

Product Description

GENERAL SVC Single-phase high accuracy full automatic AC voltage stabilizers is made of regulator,servo motor,automatic control circuit and so in,When the voltage of the network is not steady or the load varies,the automatic sampling control circuit makes a signal to drive the servomotor to adjust the postion of the carbon brush of the regulator so as to have the output voltage regulated to the rating and to obtain the steady state.This machine has advantages of small volume,light weigh,undistorted waveform,high efficiency,reliabli performance,and time-delay,over-voltage,etc,the series of stabilizers driven,of general type,the indeel boltage stabilized sources which can be widely applied to any occasions requring power to assure the normal operation of yourpower driven equipment. TECHNICAL INDEX

Input voltage		160V~250V
Output Voltage		220V±3% 110V±4%
Phase		Single-Phase
Frequency		50~60Hz
Adjusting Time		<1S (When input voltage has a change of 10%)
Max Of		0.5KVA	1KVA	1.5KVA	2KVA	3KVA	5KVA	10KVA	15KVA	20KVA	30KVA
Output Current		2A	4A	6.5A	8A	12A	20A	40A	60A	80A	120A
Protection Over Voltage		245±5V
Delay		Short Deley: 3~7sec Long Delay: 3~7min
Ambient Temperature		-5~+40ºC
Temperature Rise		<60ºC (full load)
Relative Humidity		<90ºC
Wave Form Distortion		No Wave Form Distortion
Efficiency		>95%
Insulation Resistance		≥2mΩ

---
