Cwan-2 Piston Compressor Nebulizer

Product Description

Piston Nebulizer---CWA Brand (Manufacturer)
CWAN-2
1: Power: 220/230V AC 50/60Hz
2: Power Consumption: 180VA
3: Medication Capacity: 5ml
4: Particle Size: 0.5 to 10um
5: MMAD: 4.0um
6: Average Nebulization Rate: Min 0.2ml/min.
7: Noise Level: About 40dBA
8: Compressor Pressure Range: 2.5-3.0 bar
9: Air Flow Range: 8-12LPM
10: Operation Temperature Range: 10° C--40° C (50° F--104° F)
11: Operation Humidity Range: 10 to 95% RH
12: Storage Temperature Range: -20° C--70° C(-4° F--158° F)
13: Storage Humidity Range: 10 to 95%RH
14: Dimension(LxWxH): 276x182x100mm
15: Weight: 2.0kgs
16: OEM: Available
17. Quality Guarantee: 3years
18. Advantage: 24hours continuous working
Description:
This compressor nebulizer drives the liquid medicine to spray to small panel by the high-speed air flow produced by the compressor, then the liquid medication will change into 0.5um~6um atomized particles which can be easily inhaled into respiratory system along with human breath to cure respiratory diseases such as acute and chronic tracheitis, bronchitis, sore throat and asthma, etc. It is the ideal choice for hospital, clinic and family. Features:
Reliable Motors
The high wear-resistant oil-free pure copper compressor ensures durable and efficient operation. It can provide sufficient airflow for atomization under the premise that the noise is lower than 35dB(A).
Elegant and User-Friendly Design
The elegant design is in line with most people's aesthetics. One button operation and easy cleaning makes it convenient to use for everybody.
Ideal Choice for hospital, Clinic and Family
Compressor Nebulizer features for good curative effect, comfortable use experience, little liquid medicine residue, high medicine utilization rate, easy cleaning and long service life. It is the ideal choice for hospital, clinic and family.
Loaded Accessories
You will get a mouthpiece, a adult mask and a child mask. The loaded accessories makes this product suitable for all ages.
Standard packing list:
1*Compressor Nebulizer
1*Nebulizer Cup
1*Adult Face Mask(With a strap)
1*Child Face Mask(With a strap)
1*Mouthpiece
1*Airway Tube
5*Air Filter
1*Protective Tube
1*User Manual
Main performance:

Name	Compressor Nebulizer
Model	CWAN-2
Power Supply	220VAC ± 10% 50Hz 220VAC ± 10% 60Hz 110VAC ± 10% 50Hz 110VAC ± 10% 60Hz
Noise	<65dB(A)
Particles	Size Range: 0.5um~6um
	MMAD: 2um
Working Pressure	Extreme Pressure: 160Kpa~270Kpa
	Nebulizing Pressure: 60Kpa~140Kpa
Atomization	Air Flow: >8L/min
	Atomization Rate: >0.2ml/min
Nebulizer Cup	Appropriate Volume: 2ml~8ml
	Residue: 0.7ml
Environment	Operating Temperature: 5 ºC to 40 ºC
	Storage Temperature: -25 ºC to 70 ºC
	Operating Humidity: 15%-85%
	Storage Humidity: 10%-93%
	Operating Atmospheric Pressure: 86kpa-106kpa
	Storage Atmospheric Pressure: 60kpa-106kpa
Safety	Type of protection against electric shock: Class 2
	Degree of protection against electric shock: Type B applied part
Product	Product Size: 151*199*98 mm
	Net Wight: 1.8Kg
	Unit Package: 290*130*180mm
Carton	Carton Size: 570*350*330mm
	QTY/Carton: 10pcs
	G.W./Carton: 20Kg

---
