Stationary Rock Crushing and Screening Equipment 100 Tph Mobile Stone Aggregate Crusher Plant for Sale

Product Description

Sinoway Aggregate Plant
The Crushing and screening complete set system used in hydropower, urban construction, highway construction and other industries can manufacture a variety of specifications of aggregate or artificial sand through the dry, wet process. It can support different types of feeder, crusher, sieving equipment, plastic equipment, sand separator (dry method sand), sand washing equipment (wet sand) and transportation equipment. It is equipped with different types of dedusting and PLC control system to realize crushing and sorting processing of different properties of stone and manufacture various specifications of aggregate(5-80mm) and artificial sand (0.5-6mm). The aggregate product is cubic and high quality with few flakes. The specifications of crushing, screening and mechanical sand complete set system are of 30-600m3/h, we provide its system design, manufacture, installation guidance and commissioning, engineering contracting services.
Features and technology advantages
1. High automation of sand and stone production line.
2. High production efficiency, low operation cost and high output, high income.
3. The size of grain size can be adjusted, the crushing ration is high, and the energy saving.
4. The size of the product is uniform, and the grain shape is good, which is in line with the national high speed material standard
The artificial sand and aggregate system is mainly composed of crushing, screening, conveying and other equipments to form an complete crushing and screening system. According to the actual production needs, the material is processed into aggregates and sand. The block material enters into the primary crushing equipment through the feeding equipment and further crushed by the secondary or multistage crushing, the crushed material shall be classified by screening equipments and divided into different specifications of finished product. If the finished product contains lots of soil, it needs to be washed to meet the qualified products.
Sinoway treat Service as a significant segment in our value chain, from the moment you get in touch with Sinoway, our commitment to service is a complete guarantee that we will make every effort to be there for you. That is our pledge to you. We wish to not just satisfy but surpass the expectations of our customers.
Equipment configuration

Capacity (m3/h)	Equipment model/quantity								Power (Kw)
	Feeder	Primary crusher	Checking screen	Fine jaw crusher	Cone crusher	Impact crusher	Product screen	Sand making machine
30	GZD9020	PE400×600				PF0808	3YK1236	VSI550	100-120
				PE250×1000/2
50	GZD9030	PE400×600	YK1230			PF1007	3YK1530	VSI7611	120-160
				PEX250×1200
80	GZD9638	PE600×750	YK1236	PEX250×1200/2			3YK1548	VSI7611	160-200
						PF1007/2
						PF1010
					PYB900
100	GZD9638	PE600×900	YK1536	PEX250×1200/3			3YK1548	VSI7611	240-400
						PF1210
					PYB1200
150	GZD1142	PE750×1060	YK1536	PEX250×1200/5			3YK1848	VSI8518	450-600
					PYB1200
						PF1214
200	GZD1149	PE900×1200	YK1548	PEX250×1200/6			3YK2160	VSI9526	550-800
					PYZ1750
						PF1210/2
250	GZD1342	PE900×1200	YK1848	PEX300×1300/4			3YK2160	VSI9526	560-800
					PYZ1750
						PF1320
300	GZD1342	PE1000×1200	YK1848	PEX300×1300/5			2YK1548/2	VSI1140	600-880
					PYZ1750
						PF1214/2
350	GZD1360	PE1200× 1500	YK2148	PEX300×1300/6			2YK1848/2	VSI9526/2	700-900
					PYB1750
						PF1215/2
400	GZD1560	PE900× 1200/2	YK2148		PYB1750		2YK1848/2	PL1200/2	800- 1000
						PF1315/2
500	GZD1560	PE1000× 1200/2	YK2160		PYZ2200		2YK2148/2	VSI1140/2	900- 1200
						PF1320/2
600	GZZ2060	PE1000× 1200/2	YK2460		PYZ2200		2YK2148/2	VSI1140/2	960- 1290
						PF1315/3

Any change of technical parameters, there is no further notice.

---
