Full Servo Adult Pull up Pants Machine Product Description
| CSG-APUP350 Full Servo Adult Pull up Pants Machine |
|
| Product Stucture |
| 1 | 3-pcs type adult pull up pants |
| 2 | 2-pcs type adult pull up pants |
| Main Technical Parameters |
| 1 | Supply,3 phase,380V,50Hz |
| 2 | Power:550KW(Excluding hot melt applicator and Compressor) |
| 3 | Production speed:250/350pcs/min |
| 4 | Qualification:≥97% |
| 5 | Outside dimension(m):45 x 10 x 5 (L×W×H)( for reference) |
| Main Function and Features |
| (I)Mechanical part |
| 1 | Pulp SAP mixing product and laminating core product are compatible |
| 2 | High-density ultra-thin fluff core forming system |
| 3 | Waist Sealing:Ultrasonic sealing process, support for tension customization,soft feel,and good appearance |
| 4 | Waist Sealing:no glue laminating,Ultrasonic sealing process, improving softness and saving cost |
| 5 | Support elastic film waist making process |
| 6 | With web guiding system |
| 7 | Packing machine or stacker (Option) |
| 8 | Dust collection filter system (option) |
| (II)Electric part |
| 1 | Full servo motor drive and PLC control |
| 2 | One button for size change, quick and less waste |
| 3 | High-precision tension control system,active un-winding and auto-splicing system |
| 4 | i-MAS Intelligent equipment mangement and analysis system |
| 5 | Material auto-splicing end joint limit at 3m, and decrease material wastage |
| 6 | Material automatic inspect,broken and lost alarm system |
| 7 | Vision inspection system (option) |
| 8 | Elastic BTSR tension control system, single tension adjust(option) |
Sales Service
ZHEJIANG NEW YUHONG INTELLIGENT EQUIPMENT CO., LTD.
Boasting nearly three decades of expertise in designing and manufacturing world-class disposable hygiene machines, ZHEJIANG NEW YUHONG INTELLIGENT EQUIPMENT CO., LTD. has excelled in producing a variety of machines, including sanitary napkin machines, under pad machines, and adult & baby diaper machines. With an impressive capacity to deliver over 30 production lines annually, we have successfully supplied thousands of state-of-the-art machines to satisfied customers globally. We are especially renowned for our impeccable reputation in China, South-East Asia, the Middle-East, and Europe.
