Product Description

Product Description
1.Three leg core:Made of grain oriendted low loss electrolami nations insulated on both sides.2.Resilient spacers:To insulate core and windings from mechanical vibrations,resulting in low noise emissions.3.HV winding:Consisting of vacuum potted single foil type aluminum or copper coils.4.LV winding:Made of copper or aluminum strip.Turns firmly glued together by means of insulating sheet wrapper material.5.Insulation:Mixture of epoxy resin and quatrz powder.Makes the transformer maintenance free,moistureproof,tropicalized,flame resistant and self extinguishing.6.Clamping frame and truck:Rollers can be swung around for lengthways or sideways travel.7.LV terminals:Normal arrangement:top,rear.Special version:Bottom,available on request at extra charge.8.HV terminals:Variable arrangerments,for optimal station design.HV tapping links on low voltage side for adjust ment to system conditions,reconnectable in deenergized state. Three Phase Dry Type Transformer Core
The core is beveled and stepped for maximum performance and minimal bulk. After the magnetic steel is produced by the cutting machine, it is continuously cut into specific lengths by the automatic stacking machine, and then automatically stacked. The correct size is ensured during the entire stacking and assembly process to ensure the high quality of the product.
Dry Type Distribution Transformer Winding
The low voltage winding adopts the whole section of copper foil, which is wound on the special low-voltage foil winding machine with the F-grade insulation. The foil coil solves the outstanding problems such as low voltage, high current coil winding, high short-circuit stress, unbalanced ampere turns, poor heat dissipation effect, windingspiral angle, unstable manual welding quality and so on. At the same tim-e, the winding ends of our company aresealed with resin, cured and formed, moisture-proof and antifouling. The lead copper bar is automatically welded byargon arc welding.
Dry Type Power Transformer Accessories
All the accessories you need to customize our products to your needs.
The casing is made from bolts on a steel plate with removable panels for attachment and tape. Depending on the application and your requirements, the surface treatment can be galvanized, painted. The design is optimized to ensure the required cooling of the transformer at all levels of protection. The enclosure can be shipped assembled on the transformer or flat packed for on-site assembly.
Other Accessories
cooling fan.
Temperature monitoring unit (thermal control system)Product Feature
1. Low loss, low noise, low partial discharge.2. Strong anti-short circuit capability and high anti-lightning impact level.3. Excellent moisture resistance for operation at 100% relative humidity.4. Strong overload capability for long-term operation at 150% loading.
Temperature control device:The transformer adopts the BWDK series signal thermometer. The temperature measuring element is embedded in the upper half of the low-voltage coil, which can automatically detect and display the respective working temperature of the phase coil, and has the function of over temperature alarm and trip.
More Product Parameters
SCB10 10kV Epoxy-resin Insulation Dry-type Transformer

Rated Capacity(kVA) Voltage Combined Vector-group No-load Loss(W) 75ºC Load Loss(W) No-load current(%) Short-circuit Impendance(%) High voltage(KV) Tapping Ranges Low voltage(KV) 30 6 6.3 6.6 10 10.5 11 ±5% ±2×2.5% 0.4 Dyn11 Yyn0 190 710 2.4 4 50 270 1000 2.4 80 370 1380 1.8 100 400 1570 1.8 125 470 1850 1.6 160 540 2130 1.6 200 620 2530 1.4 250 720 2760 1.4 315 880 3470 1.2 400 980 2990 1.2 500 1160 4880 1.2 630 1340 5880 1.0 630 1300 5960 1.0 6 800 1520 6960 1.0 1000 1770 8130 1.0 1250 2090 9690 1.0 1600 2450 11730 1.0 2000 6050 14450 0.8 2500 3600 17170 0.8 1600 2450 12960 1.0 8 2000 3050 15960 0.8 2500 3600 18890 0.8

SCB1110kV Epoxy-resin Insulation Dry-type Transformer

Rated Capacity(kVA)	Voltage Combined			Vector-group	No-load Loss(W)	75ºC Load Loss(W)	Short-circuit Impendance(%)	Size(mm)	Track gauge(mm)
	High voltage(KV)	Tapping Ranges	Low voltage(KV)
30	6 10 10.5 11	±5%	0.4	Dyn11 Yyn0	180	560	4	800x660x940	400x400
50					260	730		830x690x990	400x400
80					320	1120		860x690x1020	400x400
100					350	1370		900x720x1060	550x550
125					430	1620		940x740x1080	550x550
160					480	1900		1220x770x1100	550x550
200					540	2100		1240x780x1170	550x550
250					650	2560		1390x800x1200	550x550
315					760	3010		1410x820x1230	550x550
400					780	3690		1500x860x1270	660x660
500					840	4300		1520x870x1520	660x660
630					1040	5160	6	1600x890x1410	660x660
800					1240	6290		1660x950x1460	820x820
1000					1430	7380		1760x970x1500	820x820
1250					1500	8830		1800x1090x1620	820x820
1600					1710	10580		1870x1100x1700	820x820
2000					2200	12810		1980x1180x1800	1070x1070
2500					2650	15080		2090x1260x1930	1070x1070

SCB13 10kV Epoxy-resin Insulation Dry-type Transformer

Rated Capacity(kVA)	Voltage Combined			Vector-group	No-load Loss(W)	Load Loss under Different Insulation and Heat Resistance Levels			No-load current(%)	Short-circuit Impendance(%)
	High voltage(KV)	Tapping Ranges	Low voltage(KV)			B(100ºC)	P(120ºC)	H(145ºC)
30	6 6.3 6.6 10 10.5 11	±5% ±2×2.5%	0.4	Dyn11 Yyn0	150	670	710	760	2.4	4.0
50					215	940	1000	1070	2.4
80					295	1290	1380	1480	1.8
100					320	1480	1570	1690	1.8
125					375	1740	1850	1980	1.6
160					430	2000	2130	2280	1.6
200					495	2370	2530	2710	1.4
250					575	2590	2760	2960	1.4
315					705	3270	3470	3730	1.2
400					785	3750	3990	4280	1.2
500					930	4590	4880	5230	1.2
630					1070	5530	5880	6290	1.0
630					1040	5610	5960	6400	1.0	6.0
800					1215	6550	6960	7460	1.0
1000					1415	7650	8130	8760	1.0
1250					1670	9100	9690	10370	1.0
1600					1960	11050	11730	12580	1.0
2000					2440	14450	14450	15560	0.8
2500					2880	17170	17170	18450	0.8

SCB14 10kV Epoxy-resin Insulation Dry-type Transformer

Rated Capacity(kVA)	Voltage Combined			Vector-group	No-load Loss(W)	Load Loss under Different Insulation and Heat Resistance Levels			No-load current(%)	Short-circuit Impendance(%)
	High voltage(KV)	Tapping Ranges	Low voltage(KV)			B(100ºC)	P(120ºC)	H(145ºC)
30	6 6.3 6.6 10 10.5 11	±5% ±2×2.5%	0.4	Dyn11 Yyn0	130	605	640	685	2.4	4.0
50					185	845	900	965	2.4
80					250	1160	1240	1330	1.8
100					270	1330	1415	1520	1.8
125					320	1565	1665	1780	1.6
160					365	1800	1915	2050	1.6
200					420	2135	2275	2440	1.4
250					490	2330	2485	2665	1.4
315					600	2945	3125	3355	1.2
400					665	3375	3590	3850	1.2
500					790	4130	4390	4705	1.2
630					910	4975	5290	5660	1.0
630					885	5050	5365	5760	1.0	6.0
800					1035	5895	6265	6715	1.0
1000					1205	6885	7315	7885	1.0
1250					1420	8190	8720	9335	1.0
1600					1665	9945	10555	11320	1.0
2000					2075	12240	13005	14005	0.8
2500					2450	14535	15445	16605	0.8

SCB18 10kV Epoxy-resin Insulation Dry-type Transformer

Rated Capacity(kVA)	Voltage Combined			Vector-group	No-load Loss(W)	Load Loss under Different Insulation and Heat Resistance Levels			No-load current(%)	Short-circuit Impendance(%)
	High voltage(KV)	Tapping Ranges	Low voltage(KV)			B(100ºC)	P(120ºC)	H(145ºC)
30	6 6.3 6.6 10 10.5 11	±5% ±2×2.5%	0.4	Dyn11 Yyn0	105	605	640	685	2.4	4.0
50					155	845	900	965	2.4
80					210	1160	1240	1330	1.8
100					230	1330	1415	1520	1.8
125					270	1565	1665	1780	1.6
160					310	1800	1915	2050	1.6
200					360	2135	2275	2440	1.4
250					415	2330	2485	2665	1.4
315					510	2945	3125	3355	1.2
400					570	3375	3590	3850	1.2
500					670	4130	4390	4705	1.2
630					775	4975	5290	5660	1.0
630					750	5050	5365	5760	1.0	6.0
800					875	5895	6265	6715	1.0
1000					1020	6885	7315	7885	1.0
1250					1205	8190	8720	9335	1.0
1600					1415	9945	10555	11320	1.0
2000					1760	12240	13002	14005	0.8
2500					2080	14535	15445	16605	0.8

Payment Term

Payment Terms	T/T	EXW	30% T/T in advance, the balance to be paid before dispatch
		FOB
		CIF	30% T/T in advance, the balance to be paid against the copy of B/L
		CFR (C&F)
	L/C	Irrevocable L/C at sight could be accepted if amount above US $50,000.00
Delivery Time	7 to 10 working days after receiving advanced payment

FAQ
Q:what's your major products?
A: oil immersed transformer, dry type transformer, Transformer Substation, High and Low Voltage SwitchgearQ: Can your product be customized?
A: Considering differences in voltage, frequency and other special transformer product in different countries and regions, our product can be customized according to your requirements.Q: When can I get the price?
A:Usually we quote within 24 hours after we get your inquiry.Q: What about lead or shipping time?
A: The lead time depends on the quantity you ordered, generally within 15 days upon receipt of advance payment.Q: What is the price of shipping?
A: Depending upon the port of delivery, prices varies.Q: Do you offer guarantee for the products?
A: Yes. We offer at least one years guarantee for all of our transformers.Q: Your Advantage?
A: 15 years experience, Advanced production equipment, Stable quality, Fast delivery, Professional & good & Prompt service. Also some free parts can be provided for you.

---
