| Standardization | ISO 15407-1 |
| Frame size | 26 mm |
| Actuating control | single solenoid |
| Return type | With spring/air spring return |
| Switching principle | 5/2 |
| Version | Spool valve, positive overlapping |
| Housing | Polyamide,Polyoxymethylene |
| Sealing material | Acrylonitrile butadiene rubber |
| Free of substances that impair surface wetting in the coating process |
| Connector standard | EN 175301-803, form C |
| Protection class | IP65 |
| Port size | EN 175301-803, form C |
| Type | Plug |
| Qn 1▶2 | 1010 l/min |
| Qn 2▶3 | 1010 l/min |
| Nominal flow Qn | 1010 l/min |
| Compressed air connection input | base plate DIN ISO 15407-1 |
| Compressed air connection output | base plate DIN ISO 15407-1 |
| DC operating voltage | 24 V |
| Version | Spool valve, positive overlapping |
| Pilot | External |
| Sealing principle | Soft sealing |
| Connection type | Plate connection |
| Standards | ISO 15407-1, 26 mm |
| Connector standard | EN 175301-803, form C |
| Certificates | Free of substances that impair surface wetting in the coating process |
| Working pressure min./max. | 0 … 16 bar |
| Control pressure min./max. | 3 … 10 bar |
| Ambient temperature min./max. | -15 … 50 °C |
| Medium temperature min./max. | -15 … 50 °C |
| Medium | Compressed air |
| Max. particle size | 50 µm |
| Oil content of compressed air | 0 … 5 mg/m³ |
| Nominal flow Qn | 1010 l/min |
| Compressed air connection | according to ISO 15407-1 |
| Protection class with connection | IP65 |
| Duty cycle | 100 % |
| Typ. switch-on time | 34 ms |
| Typ. switch-off time | 35 ms |
| Mounting screw | M4 with hexagon socket |
| Mounting screw tightening torque | 2,5 Nm |
| Weight | 0,21 kg |
