Sanitary Sample Coolers DS-01

Product Details

Product Description

Product Description
SQ2 Sanitary Sample Cooler specifically for the safe taking of high quality chemistry/TOC, conductivity and microbiological samples from steam or heated water systems. The SQ2 Sanitary Sample Cooler is also available for “on line” applications.
The SQ2 Sanitary Sample Coolers are ideal for use in centralised sampling systems, as stand-alone coolers for point-of-use applications or as portable coolers to allow samples to be taken from multiple locations.
DS SEIES Sanitary Sample Coolers are from the same stable as the SQ1 Steam Quality Test Kit, which is the choice of validation professionals throughout the world.
Technical Data
ample connection： 1/2" Tri-Clampⓒ compatible
Cooling water connections： 1/2" BSP or NPT options
Coil surface area： 0.113 m2 (1.217 ft2)
Coil design pressure ： 15 barg (215 psig)
Shell dimensions ： 76.3 mm dia. x 250 mm high
Shell design pressure： 110 barg (145 psig)
Capacities (approximate) Steam： 160 ml/minute
*Water： 500 ml/minute
*Assumes cooling water at 20˚C and flow @ 6 litres/minute

---
