Pet Preform / Plastic Cap Injection Moulding Machine with Servo Motor

Product Description

Injection Molding Machine
(Model: SZ-3800A)

Screw diameter	mm	65	70	75
Shot weight	gram	966	1120	1286
Injection capacity	cm3	1061	1231	1413
Injection pressure	Mpa	203	175	152
Injection stroke	mm	320
Screw Speed	rpm	150
Screw torque	N.m	2860
Heating power	kw	25
Clamping force	ton	3800
Opening stroke	mm	680
Mould height	mm	250~710
Space between tie bars	mm	680×680
Ejector force/stroke	KN/mm	90.7/170
Oil pump motor	kw	37
Machine Size	m	6.8×2.0×2.3
Packing size	m	7.5×3×2.5
Machine weight	ton	15

Advantages of small injection molding machine
1 HIGH LOAD OIL BEARING
The movable part of machine hinge and sliding adopt oil-bearing, decrease the use of lubricating oil, reduce maintenance costs and reduce oil to enhance the clean lines of the machine.

2 SYNCHRONOUS HYDRAULIC PRECISION MOULD ADJUSTMENT MECHANISMS
Hydraulic motor, the center location of gear module mould adjustment system, enable the mold adjustment system more perfect.

3 INTELLIGENT DISPLACEMENT DISTRIBUTION OF LUBRICATION SYSTEM
Intelligent displacement oil distribution system, equal distribution of oil and high efficiency of lubrication, extension the life of the reamer.

4 DESIGN AND RESERVE LARGE AUXILIARY SPARE SPACE.
Convenience of the circuit connection for the precision mold of electricity, gas, water oil and configuration flexible delivery device.

5 ADJUSTABLE JUNIOR WARE-RESISTING FEET SLIP
Adjust special polymer wear-resisting materials containing flattering feet, adjustable height, balance weight, durable, and clean.

---
