Fully Automatic HDPE 5liter Plastic Bottle Extrusion Blow Molding Machine

US$23,000.00-52,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
EB70U
Warranty
1 Year
Plastic Proceed
PP, HDPE, PE, ABS/PP, PE/PP, HDPE/PP
Core Components
PLC, Engine, Bearing, Gearbox, Motor, Pressure Ves
Applicable Industries
Energy & Mining, Hotels, Home Use, Machinery Repai
Showroom Location
Egypt, Turkey, United Kingdom, United States, Viet
Transport Package
Fixed in The Container with Wire Rope, Suitable Fo
Trademark
Powerjet
Origin
China
HS Code
8477401000
Production Capacity
5000 Sets Per Year

Product Description

Product Description
EB70U High-speed Double Station Extrusion Blow Molding Machine
Powerjet Single Station Extrusion Blow Molding Machine EB70U is specialized for manufacturing bottles and containers with Max 7L.Max Bottle Capacity - 7(L)Clamping Force - 85/110(KN)Extrusion Weight(HDPE) - 80~120(kg/hr)Applications - Wide Range Of Bottles For Daily necessities, toiletries, beverages, water tanks, laundry detergent/shower gel/motoroil bottles, etc

Detailed Photos
FEATURES:
1:Toggle balance clamping structure, with platen opening & clamping and mold platen movement by linear guide, to achieve low friction and high speed.
2 Based on the Finite Element Analysis design, and platen, toggle, and platen frame are made in high-intensity nodular cast iron.
3:High-speed mold clamping oil cylinder with differential speed function, and high-speed mold moving cylinder with special anti-shock cushion valve structure.
4:Specially designed to screw with a high L/D ratio ensures good plasticizing and stable extrusion; high precision and no part line die head guarantees customers' top quality requirement.
5:Multi-screw & multi-die heads can be adopted to improve the quality of the product and lower the cost of material.
6:Multiple-way PID-controlled temperature heating is precise and stable.

Product Parameters
MODEL UNIT EB70U75S
EB70UW75S
EB70U85S
EB70UW85S
EB70U75S-plus
EB70UW75S-plus
EB70U85S-plus
EB70UW85S-plus
Max.Product L 7 7 10 10
Clamping Force kN 85/110 85/110 160 160
Max.Mold Size(WxH) mm 480x450 480x460
mm 580x440 580x420
Screw Diameter mm Φ75 Φ85 Φ75 Φ85
Screw L/D Ratio L/D 24 24 24 24
Screw Rotary Speed RPM 65 60 65 60
Extrusion Weight(HDPE) kg 80 120 80 120
Extrusion Motor Power kW 22 30 22 30
Pump Motor Power kW 11 11 11 11
Heating Capacity kW 19 21 19 21
Operation Pressure Mpa 0.6~0.8 0.6~0.8 0.6~0.8 0.6~0.8
Air Consumption m³/min 3.0 3.0 3.0 3.0
Cooling Water Consumption(25ºC) L/min 100 100 100 100
Machine Dimension (LxWxH) mm 4220x3170x2600 4880x3490x2700
Machine Weight kg 6000 6200 6100 6300
