Champion PET Flat Pasting Film Extrusion Production Line/Plastic Film Extruder Making Machine Furniture Decorative PET Film Extrusion Machine

Product Description

Product Description
PET flat pasting film extrusion machine -- PET sheet extrusion machine
The PET sheet product has been widely used in our life, such as food container packages, fruit and vegetables container packages, medicine packages, cups, folding box, electric packages, furniture decoration, etc. Here, we will show you the special machine for PET flat pasting film extrusion machine.
The Complete Extrusion System
1. Automatic vacuum feeding system, to ensure the material feeding continuously. Equip the alarm device, it will remind you when the material is lower than the material level.
2. Independent R&D twin screw extruder. The special design of screw elements and barrel for PETG material, with good performance, to keep the good plasticizing.
3. The complete pressure monitoring, we can get the exact pressure all the time. Ensure that the machine running is always stable.
4. Top-quality auxiliary equipment for the machine, the melt pump, screen changer, die mould, etc.
5. The highly quality roller calender forming machine ensures the uniformity of the PET film thickness. The mirror surface roller keeps the good sheet surface.
6. The scanner will give you the accurate feed back of sheet thickness.
7. Automatic winding system will provide you easier operation at the high-speed production. Auto cutting, auto winding.
Our Control System
1. PLC control for complete PET sheet/film extrusion machine.
2. SIEMENS high-end series CPU.
3. SIEMENS electrical elements, SIEMENS inverter and servo motor.
4. Centralized control, browse all the parameters in the Siemens screen touch, such as pressure, temperature, electric current, speed, etc.
5. The unique function of "key to acceleration", operation easier.

Product Parameters

Material	PETG
Sheet structure	Single layer sheet
Width	600-1300mm
Thickness	0.05-0.07mm
Output capacity	550kg/h

The Application of PET Flat Pasting Film
Widely used in building glass, wardrobe, furniture, decoration veneers, etc.
The Shipping and Packaging
1. The machine will be tested in CHAMPION factory before shipping. Ensure the extrusion equipment is no problem.
2. Wooden cases, wooden pallet and PE film and stretch film for equipment.
3. Cleaned of oil at the metal surface rust.
4. The shipping information, CHAMPION will follow up and update timely.
FAQ 1. Is Champion a manufacturer or trading company?
ZHEJIANG CHAMPION MACHINERY is the manufacturer of plastic extrusion machine. We have the 20000+ square meters production base. Our factory is in Huzhou City, China. Near the Shanghai port.
If you want to visit CHAMPION factory, please contact Miss. Sarah for online visit.
2. How can I get the detailed list of the machine?
First, you have to tell us the detailed product parameters:
1. Final sheet width
2. Final sheet thickness
3. Capacity
4. Application of sheet product
5. The structure of sheet, if you don't know. You can send your product pintures to us.
After we receive your parameters, we will give you the suggestion.
3. How you can make sure the after service?
First, the extrusion machine from Champion Machinery is intelligent extrusion machine, equipped with the net transmission technology. We can check your problem by remote control.
Second, we will test the machine before shipping to make sure the equipment is running stable. We will send engineer to your factory for the equipment installation and training.
Third, we have the after service group for each customer. The customer can find us at any time.
4. What's the delivery time?
It's about 120 days. According to the detailed specification, it will be little difference. More information please contact CHAMPION person.

More details, please contact us. We are always here!!!

---
