Basic Info.
Certification
ISO9001, TUV
Tank Marerial
Aluminum 6061
Type
High Pressure Storage & Transportation Equipment
Transport Package
Exported Standard Carton
Specification
61.5mm*61.5mm*290mm
Production Capacity
5000PCS/Day
Product Description
Products Descript
| Type | Outside Diameter (mm) | Water Capacity (L) | Height (Withoutvalve) (mm) | Weight(Without valve,cap) (Kg) | Working Pressure (Mpa) | Design Wall Thickness (mm) |
| LW-60-0.5-20H | 60 | 0.5 | 285 | 0.6 | 200 | 3.1 |
| LW-75-0.7-15H | 75 | 0.7 | 295 | 0.9 | 150 | 4 |
| LW-82-0.7-15H | 82 | 0.7 | 235 | 0.9 | 150 | 4.2 |
| LW-89-1.0-15H | 89 | 1.0 | 269 | 1.2 | 150 | 4.5 |
| LW-89-1.4-15H | 89 | 1.4 | 345 | 1.4 | 150 | 4.5 |
| LW-108-1.0-15H | 108 | 1.0 | 210 | 1.3 | 150 | 5.5 |
| LW-108-1.4-15H | 108 | 1.4 | 264 | 1.6 | 150 | 5.5 |
| LW-108-2.0-15H | 108 | 2.0 | 346 | 2.1 | 150 | 5.5 |
| LW-108-2.5-15H | 108 | 2.5 | 413 | 2.5 | 150 | 5.5 |
| LW-120-2.0-15H | 120 | 2.0 | 320 | 2.7 | 150 | 6.1 |
| LW-120-2.5-15H | 120 | 2.5 | 369 | 3.0 | 150 | 6.1 |
| LW-120-2.8-15H | 120 | 2.8 | 398 | 3.2 | 150 | 6.1 |
| LW-120-3.2-15H | 120 | 3.2 | 437 | 3.5 | 150 | 6.1 |
| LW-140-4.0-15H | 140 | 4.0 | 420 | 4.2 | 150 | 7.1 |
| LW-140-5.0-15H | 140 | 5.0 | 500 | 4.9 | 150 | 7.1 |
| LW-140-6.0-15H | 140 | 6.0 | 580 | 5.6 | 150 | 7.1 |
| LW-140-8.0-15H | 140 | 8.0 | 741 | 7.2 | 150 | 7.1 |
| LW-140-5.0-20H | 140 | 5.0 | 525 | 6.3 | 200 | 9.3 |
| LW-140-6.0-20H | 140 | 6.0 | 652 | 7.98 | 200 | 9.3 |
| LW-159-10.0-15H | 159 | 10.0 | 730 | 8.8 | 150 | 8 |
| LW-184-9.0-20H | 184 | 9.0 | 575 | 12.0 | 200 | 12.2 |
| LW-184-10.0-20H | 184 | 10.0 | 620 | 12.9 | 200 | 12.2 |
| LW-184-11.0-20H | 184 | 11.0 | 665 | 14.2 | 200 | 12.2 |
| LW-184-12.0-20H | 184 | 12.0 | 710 | 15.4 | 200 | 12.2 |
| LW-203-12-15H | 203 | 12.0 | 567 | 11.8 | 150 | 10.3 |
| LW-203-15-15H | 203 | 20.0 | 873 | 17.0 | 150 | 10.3 |
| LW-203-21.3-15H | 203 | 21.3 | 962 | 19.9 | 150 | 10.3 |
| LW-204-12-20H | 204 | 12.0 | 610 | 16.5 | 200 | 13.4 |
| LW-204-15-20H | 204 | 15.0 | 735 | 18.7 | 200 | 13.4 |
| LW-204-20-20H | 204 | 20.0 | 940 | 23.4 | 200 | 13.4 |
| LW-232-29.5-15H | 232 | 29.5 | 994 | 30.2 | 150 | 11.7 |
| LW-232-30.3-15H | 232 | 30.0 | 1010 | 30.5 | 150 | 11.7 |
| LW-232-33.4-15H | 232 | 33.4 | 1126 | 31.3 | 150 | 11.7 |
| LW-232-40.0-15H | 232 | 40.0 | 1340 | 36.5 | 150 | 11.7 |
| LW-232-20.0-20H | 232 | 20.0 | 750 | 26.9 | 200 | 15.4 |
| LW-232-26.0-20H | 232 | 26.0 | 921 | 30.7 | 200 | 15.4 |
| LW-232-30.0-20H | 232 | 30.0 | 1076 | 36.4 | 200 | 15.4 |
| LW-232-31.5-20H | 232 | 31.5 | 1096 | 38.0 | 200 | 15.4 |
| LW-232-40.0-20H | 232 | 40.0 | 1365 | 44.1 | 200 | 15.4 |
| LW-250-40.0-15H | 250 | 40.0 | 1150 | 36.7 | 150 | 12.6 |
| LW-250-46.4-15H | 250 | 46.4 | 1305 | 38.7 | 150 | 12.6 |
| LW-250-47.5-15H | 250 | 47.5 | 1340 | 42.0 | 150 | 12.6 |
| LW-250-50.0-15H | 250 | 50.0 | 1590 | 39.0 | 200 | 12.6 |
| LW-250-40.0-20H | 250 | 40.0 | 1227 | 46.3 | 200 | 16.5 |
| LW-250-50.0-20H | 250 | 50.0 | 1500 | 56.0 | 200 | 16.5 |
Related Products
Company Show Based at Ningbo,China,Ningbo DSW Industry Co.Ltd As a professional pressure vessel company has been involved in the industry over thepast 10 years. we have 12000m2 size factory and 80 workers , export to South America, USA, Middle east and Asia countries.
Our company possesses three production lines for production of
various seamless gas cylinders and aluminum gas cylinders.Our major products are oxygen cylinder, nitrogen gas cylinder, carbon
dioxide gas cylinder, argon gas cylinder, other industrial gas cylinder, medical oxygen gas cylindersupply unit, etc., with wide application for fields of medical apparatus and instruments, engineering machinery, colliery rescue, gas industry, welding-cutting machinery, and chemical industry.
As we started to have well equipped workshop facilities, and go to international welding shows, our quality and up-to-date products were quickly accepted by customers from foreign countries, therefore the international trading business grew rapidly.
Q1: If you are factory or trade company? We are manufacturer with more than 20 years. Q2: What is your delivery time? We promise 20-25 days once deposit paid and workshop drawings confirmed. Q3: What is your payment terms? We accept TT and L/C at sight. Q4: What is your packing for all cylinders? We can pack all cylinders by pallet , also no pallet is available for different type cylinder. Q5: Can you provide OEM design? Yes, we can, we are factory under ourself R&D team, so custom cylinder is welcome. and we can make customerbrand name on cylinder shoulder, color, printing, etc... Q6: What is your MOQ? Our MOQ is 200 pcs. Q7: Do you have any protection for the head of the cylinder? Yes, in our factory, each cylinder is protected by standard cap which can make sure the safety of torch during the transportation. Q8: What is your advantage with other competitors? We are factory with excellent equipment and high quality control system, and our factory price is more competitive, fast shipment with high quality, our service is also best with 24 hours on line for fast reply your requestments.
>>
