High Precision Standard CNC Machine Hsk63A-GSK10-100 Tool Holder

Product Description

Product Name	HSK-ER Tool Holder ER Collet Chuck
Material	40Cr
Color	Shiny firish
Weight	2.0kg
Balance	G2.5 25000 RPM
Brand Name	Gerzhuo
Inspection	100% tool holder inspection
Used	cnc machine center

Technical specification

		L	L1	L2	D	d
HSK63A	GSK06-70	102	70	44	19.5	2-6
	GSK06-100	132	100	74	19.5	2-6
	GSK06-130	162	130	104	19.5	2-6
	GSK10-70	102	70	44	27.5	3-10
	GSK10-100	132	100	74	27.5	3-10
	GSK10-130	162	130	104	27.5	3-10
	GSK10-160	192	160	134	27.5	3-10
	GSK13-70	102	70	44	36	3-13
	GSK13-100	132	100	74	36	3-13
	GSK13-130	162	130	104	36	3-13
	GSK13-160	192	160	134	36	3-13
	GSK16-70	102	70	44	40.5	3-16
	GSK16-100	132	100	74	40.5	3-16
	GSK16-130	162	130	104	40.5	3-16
	GSK16-160	192	160	134	40.5	3-16
	GSK20-70	102	70	44	48.5	3-20
	GSK20-100	132	100	74	48.5	3-20
	GSK20-130	162	130	104	48.5	3-20
	GSK20-160	192	160	134	48.5	3-20
	GSK25-100	132	100	74	55.5	6-25
	GSK25-130	162	130	104	55.5	6-25
HSK100A	GSK10-100	150	100	71	27.5	3-10
	GSK10-160	210	160	131	27.5	3-10
	GSK13-100	150	100	71	36	3-13
	GSK13-160	210	160	131	36	3-13
	GSK16-100	150	100	71	40.5	3-16
	GSK16-160	210	160	131	40.5	3-16
	GSK20-100	150	100	71	48.5	3-20
	GSK20-160	210	160	131	48.5	3-20
	GSK25-100	150	100	71	55.5	6-25
	GSK25-160	210	160	131	55.5	6-25

Features
1, The design uses 4 deg collet clamp unilaterial, high precision repeat loading.
2, All- round nut design, low noise, small wind resistance, suitable for high speed.
