| US$0.65-0.69 | 180 Pieces (MOQ) |
| Type | Standard | IEC/EN 60898-1 | |
| Electrical features | Rated current In | A | 1,2,4,6,10,16, 20,25, 32,40,50,63 |
| Poles | P | 1,234 | |
| Rated voltage Ue | V | 230/400 | |
| Insulation voltage Ui | V | 500 | |
| Rated frequency | Hz | 50/60 | |
| Rated breaking capacity | A | 45,006,000 | |
| Rated impulse withstand voltage(1.2/50)Uimp | V | 4500(80A)/6000(1-63A) | |
| Dielectric test voltage at ind. Freq. for 1min | kV | 2 | |
| Pollution degree | 2 | ||
| Thermo-magnetic release characteristic | B,C,D | ||
| Mechanical featu res | Electrical life | t | 8000 |
| Mechanical life | t | 20000 | |
| Protection degree | IP20 | ||
| Reference temperature for setting of thermal element | ºC | 30 | |
| Ambient temperature (with daily average≤35ºC) | ºC | -5~+40 | |
| Storage temperature | ºC | -25~+70 | |
| Installation | Terminal connection type | Cable/Pin-type busbar | |
| Terminal size top / bottom for cable | mm2 | 25 | |
| AWG | 18-3 | ||
| Terminal size top / bottom for busbar | mm2 | 25 | |
| AWG | 18-3 | ||
| Tightening torque | N*m | 2 | |
| In-Ibs | 18 | ||
| Mounting | On DIN rail EN 60715(35mm)by means of fast clip device | ||
| Connection | From top and bottom |
