Zoomlion Zt20j 22.75m Telescopic Boom Lifts Aerial Work Platform 454 Kg

Product Description

2020 New ZOOMLION ZT20J 22.75m Telescopic Boom Lifts Aerial Work Platform 454 kg in Stock
Product Description
Zoomlion telescopic boom lifts are engineered to enhance working efficiency and offer greater horizontal outreach than any other type of aerial work platform. These units feature stable extension and great gradeability in rough terrain, offering a dual lift capacity of 300 kg unrestricted and 454 kg restricted. It is ideal for outdoor construction and industrial applications.
ZT20J features modularized design, light weight, commonalization and intelligence and provides a large lift capacity and high reliability. Four-wheel drive and oscillating axle system greatly improves off-road performance. With a gradeability of 45%, these machines are perfect for work in construction and industrial applications with limited access. Lubrication-free boom system minimizes equipment holding costs. Swing-out engine tray makes regular maintenance more convenient. Remote Monitoring and Rental Management System realizes on-board diagnosis, POST (power on self test), and maintenance alert for efficient fleet management.

Main Specs of Telescopic Boom Lifts
Comply with CE/ANSI/GB Standard
Model	ZT34J	ZT26J	ZT20J
Size
Work Height	36m	28.20m	22.75m
Platform Height	34m	26.20m	20.75m
Horizontal Outreach	23.50m	22.71m	16.80m
A - Stowed Length	13.50m	12.5m	10.36m
B - Stowed Width	2.49m	2.49m	2.49m
C - Stowed Height	3m	2.80m	2.78m
D - Platform Length	2.44m	2.44m	2.44m
E - Platform Width	0.91m	0.91m	0.91m
F - Wheelbase	3.80m	3.05m	2.52m
Wheelbase	2.05/3.41m	2.11m	2.13m
G - Ground Clearance	0.41m	0.40m	0.42m
Performance
Platform Capacity (Unrestricted/Restricted)	300/454kg	300kg/454kg	300kg/454kg
Drive Speed (Working)	5.5km/h	5.5km/h	6.0km/h
Gradeability	45%(24°)	45% (24°)	45% (24°)
Turning Radius (Inside)	2.80m	3.66m	2.4m
Turning Radius (Outside)	5.70m	6.86m	5.4m
Turntable Swing	360°continuous	360°continuous	360°continuous
Platform Rotation	±90°	±90°	±90°
Tail Swing	1.88m	1.60m	1.45m
Jib (Range of Articulation)	130°	130°	135°
Max. Working Slope	3°	3°	3°
Max. Wind Speed	12.5m/s	12.5m/s	12.5m/s
Power
Engine	Kohler KDI2504TCR	DEUT Z TD2.9 L4/CUMMIN QSF2.8	Duetz D2.9L4
Fuel Tank Capacity	200L	150L	130L
Control Voltage	12V DC	12V DC	12V DC
Hydraulic Tank Capacity	250L	150L	150L
Drive Mode	4WD	4WD	4WD
Steering Mode	Front-wheel/Rear-wheel/Crab	Front-wheel	Front-wheel
Tire
Type	IN445/50D710 Foam-filled Tires	15-625 Foam-filled Tires	355/55D-625 Foam-filled Tires
Weight
Gross	19200kg	18900kg	12200kg

---
