Basic Info.
Use
Medical and Food Grade Silicone Hose
Transport Package
Standard
Production Capacity
100000 Meters Per Week
Product Description
FDA Food Grade Stainless Steel Reinforced Silicone Hose with Quick Connector
Picture of product
1. Introduction
Platinum cured reinforced stainless steel silicone tube with good stability is produced in our clean room, which is braided by stainless steel & wire , suitable for bulk transfer, high pressure,Vacuum process , food processing application. This mandrel slip from the core is made of polyester textured woven wire, stainless steel and additional silicone wrap ( meet 3A, USDA, FDA, USP Class VI standard).
2. Description
Material: 100% Silicone, Platinum curing agent, stainless steel wire
Reinforcement: 4ply/multi-ply , stainless steel reinforced
Hardness, Shore 70A +/-5A
Size: I.D 1/2" to 4" (13-102mm)
Length: standard 4m, or 6m (size under 2")
Working temperature: -40°C - + 180°C
Certificate: FDA, 3A, USP class VI, USDA, ROHS, REACH
Connector type: DN series, 316L
3. Main Feature
Made from FDA-sanctioned ingredients Able to resist extreme temperature variations: -80º F to 320º F (-40°C - + 180°C ) Translucent natural color for visual contact with the flow Resilient, stretchable, and resistant to compression set Odorless, tasteless, and inert Good electrical and weatherability properties Resists UV, ozone, gases, and moisture Certified to Standard 51 for food equipment materials
4. Application:
Suitable for bulk transfer, high pressure, Vacuum process, pharmaceutical, biomedical, Load cell , Pump, Vessel or tank transfer , Laboratory, cosmetics, food processing and liquid transportation (such as: white wine, medical liquid, milk, water etc).
| NO | ID | Bend radius | Thickness | W.P | B.P |
| | mm | mm | mm | bar | bar |
| KL-SILICONE-06 | 6 | 35 | 6.5 | 15 | 40 |
| KL-SILICONE-08 | 8 | 35 | 6.5 | 15 | 40 |
| KL-SILICONE-10 | 10 | 35 | 6.5 | 15 | 40 |
| KL-SILICONE-13 | 13 | 40 | 6.0 | 13 | 40 |
| KL-SILICONE-15 | 15 | 45 | 6.0 | 13 | 38 |
| KL-SILICONE-16 | 16 | 55 | 6.0 | 13 | 38 |
| KL-SILICONE-18 | 18 | 60 | 6.0 | 12 | 36 |
| KL-SILICONE-19 | 19 | 60 | 6.0 | 12 | 36 |
| KL-SILICONE-20 | 20 | 60 | 6.0 | 11 | 36 |
| KL-SILICONE-22 | 22 | 65 | 6.0 | 11 | 35 |
| KL-SILICONE-25 | 25 | 65 | 6.0 | 11 | 33 |
| KL-SILICONE-28 | 28 | 75 | 6.0 | 10 | 32 |
| KL-SILICONE-29 | 29 | 85 | 6.0 | 10 | 32 |
| KL-SILICONE-30 | 30 | 90 | 6.0 | 10 | 32 |
| KL-SILICONE-32 | 32 | 90 | 6.0 | 10 | 30 |
| KL-SILICONE-34 | 34 | 95 | 6.0 | 9.0 | 30 |
| KL-SILICONE-35 | 35 | 100 | 6.0 | 9.0 | 30 |
| KL-SILICONE-38 | 38 | 110 | 6.0 | 8.5 | 28 |
| KL-SILICONE-40 | 40 | 110 | 6.0 | 8.5 | 28 |
| KL-SILICONE-42 | 42 | 120 | 6.0 | 8.5 | 27 |
| KL-SILICONE-44 | 44 | 130 | 6.0 | 8.5 | 26 |
| KL-SILICONE-45 | 45 | 140 | 6.0 | 8.0 | 25 |
| KL-SILICONE-48 | 48 | 150 | 6.0 | 8.0 | 25 |
| KL-SILICONE-50 | 50 | 150 | 6.0 | 8.0 | 25 |
| KL-SILICONE-51 | 51 | 150 | 6.0 | 8.0 | 25 |
| KL-SILICONE-53 | 53 | 155 | 6.0 | 7.5 | 24 |
| KL-SILICONE-55 | 55 | 160 | 6.0 | 7.5 | 23 |
| KL-SILICONE-57 | 57 | 160 | 6.0 | 7.0 | 22 |
| KL-SILICONE-60 | 60 | 170 | 6.0 | 7.0 | 21 |
| KL-SILICONE-62 | 62 | 180 | 6.0 | 7.0 | 21 |
| KL-SILICONE-63 | 63 | 180 | 6.0 | 7.0 | 21 |
| KL-SILICONE-65 | 65 | 180 | 6.0 | 6.5 | 20 |
| KL-SILICONE-68 | 68 | 220 | 6.0 | 6.0 | 19 |
| KL-SILICONE-70 | 70 | 230 | 6.0 | 5.8 | 19 |
| KL-SILICONE-75 | 75 | 240 | 6.0 | 5.6 | 18 |
| KL-SILICONE-76 | 76 | 240 | 6.0 | 5.5 | 18 |
| KL-SILICONE-80 | 80 | 280 | 6.0 | 5.0 | 16 |
| KL-SILICONE-90 | 90 | 300 | 6.0 | 4.5 | 15 |
| KL-SILICONE-95 | 95 | 320 | 6.0 | 4.0 | 14 |
| KL-SILICONE-100 | 100 | 360 | 6.0 | 3.5 | 13 |
| KL-SILICONE-102 | 102 | 360 | 6.0 | 3.5 | 13 |
