We Have All brand Replacement Accessories,If you are not see in our Shops ,Welcome leave the Message to us .
Products Description
Model :Baofeng 10R
|
Specification
|
General
|
Model NO.
| BAOFENG 10R
|
Frequency Range
| VHF136~174MHz & UHF400~520MHz
|
Channel NO.
| 128CH
|
Power Output( H/L)
| 7W/1W
|
Channel step
| 2.5KHz/5KHz/6.25KHz/10KHz/12.5KHz/20KHz/25KHz
|
Channel Voltage
| DC 7.4V
|
Battery
| 3800mAh li-ion battery
|
Model of operation
| Simplex or Semi-duplex
|
Frequency Stability
| ±2.5ppm
|
Operated Temperature
| -20ºC ~+60ºC
|
Antenna Impedance
| 50Ω
|
Consumption in standby
| 380mA
|
Transmitter
|
RF Power Output
| 7W/1W
|
Type of modulation
| FM
|
Maximum deviation(W/N)
| ≤±5KHz / ≤±2.5KHz
|
Emission class(W/N)
| 16KΦF3E/ 11KΦF3E
|
Spurious Emission
| | Receiver
|
Sensitivity(12Db SINAD)
| ≤0.20μV
|
Intermodulation
| ≥60dB
|
Audio output
| 1000mW
|
Selectivity
| 65 / 60dB
|
Features:
1.Frequency Range: 136-174MHz/400-520MHz
2. 16 Memory Channels
3.Output Power: 7W
4.Scan
5.PC Software Programmable, Encrypted Programming Software
6.VOX Function
7.CTCSS/DCS
8.Chinese and English Voice Prompt
9.Power Saving Function, Low Power Warning
10.High/Low Power Selective
11.Wide/Narrow Bandwidth Selective
12.Emergency Alarm
13.Monitor, Reverse Frequency
14.Busy Channel Lock
15.Transmitter Time-out Timer(TOT)
16.Side Key Assignment
17. 0-9 Grades Squelch Level Setting
18. DTMF Functiong
19.FM Radio(88-108MHz)
20.1750Hz call tone
Details Images
Usage
characteristicWith flashlight, good sound quality, good appearanceUsage scenariosKTV, hotel, wedding, construction site, security, parking lot, company, etc
>>
