| US$8,200.00 | 1 Piece (MOQ) |
| Items | Specifications |
| Max. swim over bed | Φ320mm |
| Max.swim over carriage | Φ150mm |
| Max.length of work piece | 450mm |
| Range of spindle speed | 150-2500rpm |
| Spindle bore | Φ40mm |
| Spindle drawn tube diameter | Φ31mm |
| Taper of spindle bore | MT5 |
| Stations of tool carrier | 4 |
| Max.size of tool post | 20mm×20mm |
| Min.setting unit of motor | (Z) 0.001mm (X) 0.001mm |
| Moving speed of post | (Z) 8 m/min (X) 4 m/min |
| Taper of tailstock quill | MT4 |
| Max. range of tailstock quill | 100mm |
| Motor power | 4KW |
| Packing size (mm) | 1820×1100×1550mm |
| Net weight/gross weight | 1000/1200 |
